*Products should be stored in dry, ventilated warehouses at temperatures below - 25°c.

Operation

Note

Preparing sauces and

salad dressings with

the addition of fresh

herbs and garlic

1500 ml

MAX (8-10)

30-45

sec.

It is recommended to pass garlic through the press, herbs

must be cut.

Preparing snacks

like pates, pastes,

mousses, vegetable

and mushroom caviar,

spreads, etc.

750 ml

MIN (1 -3)/

MED(4-7)/

MAX(8-10)

90-120

sec.

Cut dense ingredients into pieces (boiled meat, fried liver,

etc.).

Preparation of mince

from meat / fish /

poultry

750 m;

MIN (1 -3)/

MED(4-7)/

MAX(8-10)

90-120

sec.

It is recommended adding more liquid into the mince (water,

milk, cream) compared to the preparation of traditional

mince. Ideal for cooking dumplings, liver fritters).

Preparation of fruit /

berry / mousse and

sorbet

750 g

MIN (1 -3)/

MED(4-7)/

MAX(8-10)

60 sec. Frozen fruits and berries should thaw a bit, so they can be

cut with a knife.

Ice crushing

10-15

cubes

1 min.

48 sec.

Preparation of mayon-

naise

750 ml

MED(4-7)

/ MAX (8-10)

90-120

sec.

It is recommended to install in place of the measuring cup

a plastic one with a small hole at the bottom, so that the oil

came into the bowl of a blender in a thin stream and mix

better with the egg mixture.

Preparation of creams

and desserts

750 ml

MIN (1 -3)/

MED(4-7)/

MAX(8-10)

60 sec. Use chilled high fat cream, softened butter, room tempera-

ture custard, pass curd through a sieve.

Grinding garlic (onion)  100-200 g

20 sec. Use impulse mode, press and hold    for 2 sec.(10-15

times)

Operation

Note

Puree from hot boiled

vegetables

300 g

MAX (8-10) 30 sec. Recommended for babies up to 18 months, before

serving, rub through a sieve

Puree from boiled

meat, fish, poultry

300 g

MAX (8-10) 60 sec. Refers to hot products

Preparing baby food

from dry baby mixes

100-200

ml

MIN (1 -3)/

MED(4-7)/

MAX(8-10)

30 sec.

Refers to average servings, depending on the age of the

baby. You can maximum prepare 1500 ml of milk. Follow

the instructions on the dry baby mix

PREPARING BABY FOOD

cLEANING AND mAINTENANcE, Pic. D

•  Wash the cup, lid, pusher, measuring cup

and stainless steel knives with warm water

and detergent.

•  Wipe the body with a damp cloth. Never

immerse it in water because of the danger

of electric shock.

•  Thoroughly dry all parts.

The knives are very sharp, be careful.

Operation

maximum capacity

or weight of the

ingredients

Speed

Time, min Note

Pour warm water into the

cup and add detergent

800 ml

3

min.

After washing, completely disassemble the

cup’s base, rinse and dry the knives. Do not

use harsh detergents.

cLEANING THE BLENDER’S cUP

POSSIBLE PROBLEmS AND SOLUTIONS

SPEcIFIcATIONS

Model

PB1550HTD

Power consumption, W

1300

Blender’s cup capacity, ml

2000

Blender’s cup working capacity, ml

1500

Material of the blender’s cup

Tritan

Motor’s rotation frequency

28000 - 30000 rpm ± 15%

Noise level

max 80 dB

Rated voltage

220-240 V~; 50-60 Hz

Protection against electric shock

II

Storage and transportation temperature requirements

from -25°C to +35°C

Operation temperature requirements

from +5°C to +35°C

Humidity Requirements for transportation,

storing and operation

15-75%

Dimensions, mm

267×190×231

Weight, kg

2,9

Possible Problem

Possible cause

Solutions

E1

, alarm sounds 3 times.

Temperature sensor isn’t working.

Contact authorized service center.

E2

, alarm sounds 3 times.

The temperature sensor circuit is

open. The device is not assembled

correctly.

Disassemble and assemble the de-

vice correctly. If necessary, contact

authorized service center.

Er

, alarm sounds 3 times.

The motor of the device isn’t rotat-

ing, the motor may be faulty or

blocked.

Ingredients are stuck between the

blades and stop motor from rotating.

Unplug the device and remove

stuck ingredients. If necessary, con-

tact authorized service center.

СС,

 alarm sounds 3 times.

Temperature of the device is higher

than 80°С

Turn off the blender and let it cool.

If necessary, contact authorized

service center.

For information on product certification, see

 http://www.oursson.com/rus/ru/about/partners/certificates/#tab0

or ask

seller for a copy.

PRODUcT cERTIFIcATION

Reparation  must  be  performed  only  by  a  qualified  personnel  authorized  by  OURSSON AG  service

center.
