ELEmENTS OF DESIGN,

Fig. B

Measuring cup

Lid

Sealing ring

Blender’s cup

Blade unit

Device’s body

Control panel

The knives are very sharp, be careful.

UTILIZATION, Pic. c

cONTROL PANEL,

Pic. C-1

ON/OFF

 button is located on the bottom of the device’s

body:

«О»

 - power off

«I»

 - power on

Use Rotary switch for the following functions:

•

START/STOP

the device

• Changing rotation’s speed and time

 - use this button to change

the speed of rotation

 - use this button to

set the timer, 0-9 min

.

 - use this button to

crush ice

 - use this button to

make smoothies

 - use this button to

make jam

 - use this button to

heat up

 - use this button for

Turbo mode

Display,

Pic. C-2

1.

Rotation speed indication

2.  Temperature indication

3.  Time indication

Before first use, make one preparation cycle without

ingredients,

add water into the glass cup. After that, wipe

the body of the device with a dry soft cloth. Wash the cup,

lid, pusher, measuring cup and stainless steel knives with

warm water

and detergent

.

Before assembling and disassembling the device,

make sure it is unplugged.

The  device  is  equipped  with  overload  and

overheating protection. If there is an overload

or an overheating, the device will automatically

stop.  Unplug  the  device.  Let  it  cool  for  45

minutes.  After  that,  you  can  continue  using

the device.

Maximum time of continues use of the blender

is 2 minutes, after that you need to turn off the

device and let it cool for 3 minutes. Do not use

the device without water or ingredients.

When grinding hard products, do not use the

device more than for 1 minute. Let the device

cool for at least 5 minutes.

Order of Operation:

1.  Plug in the device. Turn the

ON/OFF

 switch into the

«I»

position. All the buttons and the display will light up on

the control panel, a sound signal will be heard, and then

the device will go into standby mode. To exit standby

mode, slightly press

START/STOP

 button, all the

buttons indication and the display will light up.

2.  In standby mode, install the blender’s cup onto the

motor unit according to the manual.

3.  Add required ingredients into the cup. Do not fill the

cup above the

mAX

 mark. Close the cup with lid.

NOTE:

 The volume of the ingredients must not exceed

2/3 of the volume of the cup.

4.  Select one of the preset modes (

 ),

press

START/STOP

 once.

5.  You can specify your own rotation speed and

operational time parameters. In standby mode, press

 button, with the help of rotary switch set the required

rotation speed, press   button again. To set the

operational time, repeat the steps using  .button.

Press

START/STOP

 once. The mixing/grinding process

will start automatically. To stop the blender, press

START/STOP

 again.

NOTE:

If the ingredients got stuck on the cup’s walls

during mixing/grinding, use the pusher. Pusher can be

used for stirring the ingredients during grinding/mixing.

Do not use the pusher for stirring more than 30 sec.

6.  Remove the blender’s cup from the body of the device

according to the manual.

You can open the lid only

when the cup is removed from the motor unit.

7.  Turn the switch at the bottom of the device to

OFF

position  -

«О»

. Unplug the device. After that, you can

disassemble the device

.

PRESET mODES

PREPARATION REcOmmENDATIONS

Before preparing, it is recommended to cut ingredients on 2x2x2 cm pieces. Max. amount of ingredients is shown in

the table. Follow the recommendations in the recipe book.

Operation

Note

Smoothies and milk-

shakes

1500 ml

3 min.

Puree from fresh

fruit, berries and

vegetables

1500 ml

MAX (8-10)

30-45

sec.

The ingredients must be soft or juicy (bananas, strawber-

ries, cucumbers, etc.)

Puree from cooked

fruits, vegetables and

soups

750 ml

MAX(8-10)

30-45

sec.

Do not puree ingredients with a temperature higher than

80°С

Kneading dough for

pancakes, omelets,

etc.

1250 ml

MED (4-7)

30-45

sec.

Suitable for every liquid dough

modes

Name

Description

Note

Smoothie

Preset: speed 10/3 minutes, indication  -   , set time

and speed is shown on the display, indication    is lit.

Other mode’s indications are turned off. Total time of

the mode is 3 minutes.

Timer countdown.

Ice Crushing

Preset: speed 10/10 sec., next speed 3/5 sec., next

speed 10/3 sec – total 6 cycles,  indication -  , set

time and speed is shown on the display, indication

 is

lit. Other mode’s indications are turned off. Total time of

the mode is 1 min. 48 sec.

Timer countdown.

Jam

Preset: speed 8/2 minutes, indication -   , set time

and speed is shown on the display, indication    is lit.

Other mode’s indications are turned off. Total time of

the mode is 2 minutes.

Timer countdown.

Heat up

Preset: speed 10, temperature 65°С, can be changed

to 35°C, 50 °C, 65°C, 80°C, indication  -   , set time

and speed is shown on the display, indication    ,

и   is lit. Other mode’s indications are turned off. Total

time of the mode is 9 minutes.

Timer countdown.

Turbo

Press and hold

 button, blender operates at max

speed 10. Release the button - blender will stop.

Maximum operation time 9 minutes. Other mode’s

indications are turned off.

Timer

Manually set the required preparation time: from 0-1

min/5 sec. gap, from 2-9 min/30 sec. gap. In heat up

mode you can set temperature 35°C, 50°C, 65°C,

80°C.

Timer countdown.

Rotation speed

Manually set the required rotation speed: from 1 to 10.

Under load, the rotational speed at level 1 - 3000 ±

10% rpm, at level 10 - 27000 ± 10% rpm.

PRODUcT SET

Measuring cup

 ...................................................

 1 pc

Lid

 ......................................................................

 1 pc

Sealing ring ........................................................

 1 pc

Blender’s cup

 .....................................................

 1 pc

Pusher

 ...............................................................

 1 pc

Blade unit

...........................................................

 1 pc

Motor unit

...........................................................

 1 pc

Instruction manual

 .............................................

 1 pc

Warranty card  ....................................................

 1 pc
