English

3

 En

Installing the speakers

Wall-mounting the front and

surround speakers

You can mount the front or surround speakers on a
wall as follows. The front speakers can be mounted
vertically or horizontally.

1

Install screws into a solid wall or wall support
as shown below. Use 3.5 to 4 mm (1/8")
diameter self-tapping screws.

2

Hang each speaker by its keyhole slots onto
the protruding screws.

Note

• Make  sure the shaft of the screw is seated in the

narrow part of the keyhole slot. Otherwise, the
speaker may fall.

Warnings

• Each front speaker weighs 1.0 kg (2.2 lbs.) and

each surround speaker weighs 0.45 kg (1 lbs.). Do
not mount the speakers on thin plywood or on a
wall with a soft surface material. Otherwise, the
screws may pull out of the surface and the
speakers may fall, possibly damaging the speakers
or causing personal injury.

• Do  not affix the speakers to a wall using nails,

adhesives, or unstable hardware. Long-term use
and vibration may cause the speakers to fall.

• To  avoid accidents resulting from tripping over

loose speaker cables, affix the cables to the wall.

• Mount the speakers in a wall location that will be

unlikely to result in injury to an individual’s head.

■

Front speakers

■

Surround speakers

Minimum

20 mm (3/4")

150 mm

(5-7/8")

Wall/wall
support

6 mm

(1/4")

150 mm

(5-7/8")

Vertical

Horizontal

45 mm

(1-3/4")

Wall/wall
support

6 mm

(1/4")

Minimum

20 mm (3/4")
