Thank you for choosing the Yamaha NS-P380 5.1CH Speaker Package.
Make sure the package contains the following items.

Package contents

Contents

Package contents ................................................ 1
Installing the speakers ....................................... 2

Installing the front, center, and surround

speakers ..........................................................2

Installing the subwoofer .....................................2
Wall-mounting the front and surround

speakers ..........................................................3

Connecting the speakers .................................. 4

Connection diagram........................................... 4
Connecting the power cables............................. 5

Using the Subwoofer ......................................... 6

Setting the subwoofer volume ........................... 6
Frequency characteristics................................... 6

Troubleshooting ................................................. 7
Specifications ...................................................... 7

Speaker cable,
25 m (82 ft.) x1

( To be cut into 5 lengths for
the front, center, and
surround speakers. Take
care to prevent injury when
preparing the cables.)

Subwoofer cable,
5 m (16 ft.) x1

Non-skid pads (20 pcs.) x1

(For the front, center, and
surround speakers.)

■

Subwoofer
(NS-SW380 x1)

The Subwoofer features a built-in power
amplifier and utilizes Advanced Yamaha
Active Servo Technology to provide high-
quality sub-bass sound that adds real
“punch” to your home theater.

■

Front speakers
(NS-B380 x2)

The front speakers are
2-way acoustic-
suspension speakers.

■

Surround speakers
(NS-B280 x2)

The surround speakers are full-range
acoustic-suspension speakers.

■

Center speaker
(NS-C380 x1)

The center speaker is a 2-way
acoustic-suspension speaker.

Non-skid pads:

When placing the speakers on a flat

surface, affix the included non-skid pads to the corners
of the speaker undersides, as shown. The pads will
prevent the speakers from moving around.

■

 Front speakers

■

 Center speaker

■

 Surround speakers

Non-skid pad
