www.timberk.com • electrical storage water heater

8

1. The water heater is designed to be connected to 220V single-phase
electric main. Prior to connecting make sure that parameters of the electric
main in the place of connection correspond to parameters, specified on the
identification plate with technical parameters of the appliance. You should
follow the current electrical safety code when installing the water heater.

2. The power outlet must be properly grounded. The outlet must be
designed for rated current not less than 10A, electric cable with copper
core must have cross section not less than 3x1.5 mm2 (for copper).

The power outlet and plug must always be dry to prevent current leakage.
Regularly check if the power plug is tightly connected to the outlet. Do
it in the following order: insert the power plug into the outlet, switch off
the water heater after half-hour operation and unplug the cord, check if
the plug is heated by your hand. If the plug is heated over 50°C, then to
prevent damages, accidents and fire as a result of bad electrical contact,
replace the outlet with a new one. A specialist must do this.

Connection to electric main

IMPORTANT!

If water in the installation location contains a large

amount of calcium, manganese or iron salts, then

necessary to mount a respective filter in the delivery

system to reduce the amount of scale generated in

the tank and on the heating element.

IMPORTANT!

Prior to connecting the tank water heater, make sure

that the water heater is properly grounded. Proper

grounding is important to minimize electric shocks

and risk of fire. The power cord is equipped with a plug

with a grounding pin. The appliance must be used

with a properly grounded power outlet. If the outlet,

you are intending to use, is not properly grounded or

grounded by a time-delay fuse or a circuit breaker,

contact a qualified electrician to install a proper outlet.

IMPORTANT!

To provide reliable operation and safe use of the

water heater, prior to the first run check if it is properly

connected to the 220V AC mains. The water heater to

be connected must be securely linked with the earth

circuit of your electric mains.  The waterheater must be

grounded properly, otherwise it is extremly dangerous

for life safety.

NOTE:

Do not mount additional accessories, such as a shut-off

valve, between the relief valve and the inlet nozzle.

5. Water heater with the mounted valve must be connected to the water
main – install a shut-off valve at the water inlet point. You need to connect
a drain pipe to the opening of the pressure relief of safety valve. Next you
should put a drain pipe to the sewer.

6. Connect the desired number of consumption points to the outlet nozzle,
marked red.

7. Open the shut-off tap and one of the tap assemblies. After the tank is
filled with water, as evidenced by issue of water from the cock assembly,
shut the cock assembly and check the leak integrity of all joints.
