www.timberk.com • electrical storage water heater

12

11. WIRING DIAGRAM

Thermal stoper

Heating element

indication

lampe

Thermostat

L

N

E

Q

Q

Fig. 10

IMPORTANT!

To ensure reliable operation and safe use of the

water heater, prior to the first activation check if it is

correctly connected to 230V alternating voltage mains.

The water heater to be connected must be securely

connected to an earth circuit of your electric mains.

NOTE:

Technical and any other characteristics of the

appliance can be revised.
Such changes may be introduced without warning and

prior notice to the consumers.
The manufacturer shall not be liable for changes in the

appliance’s wiring diagram that may be implemented

without notice to the consumers.

The water heater should be disposed upon the end of life. You can obtain
detailed information on water heater disposal from a representative of local
authorities.

Timberk disclaims any liability for possible damage, directly or indirectly
caused by Timberk products to people, pets, property in case if it occurred
as a result of failure to observe rules and conditions of operation, unit’s
installation, deliberate or careless actions of the consumer or third parties.

The tank water heater is not intended to be used by children, old or disabled
people without supervision. Make sure to use the water heater carefully,
do not switch between modes abruptly, closely follow recommendations,
set forth in this operation manual. Children nearby the fan heater must be
supervised by adults and must never use the unit playing games.

Guarantee card is enclosed in the product package!

13. DISPOSAL

12. TRANSPORTATION AND STORAGE

CONDITIONS

Temperature
requirements*

Humidity
requirements*

Transportation and
storage

From -30° to +50°

From 15% to 85%

(without a condensate)

We are exploring new technologies and we constantly improving the quality
of our products. That’s why specifications, design and accessories are
subject to change without any specific notice.

14. SERIAL NUMBER AND PRODUCTION DATE

Serial number, production month and year are included in ID LINE product
code. Sticker with ID LINE code is pasted on product surface. Month and
two last numbers of year is putted after symbol “-“.
