www.timberk.com • electrical storage water heater

8

2. G1/2 diameter pipes are used to connect the water heater to the water

pipeline.
3. To prevent a leakage when connecting pipes, use rubber sealing gaskets

on the threaded pipe ends.
4. Screw a relief valve to the inlet nozzle, marked blue and embossed arrow

of the water flow direction, so that the water flow direction coincides with

direction of the arrow on the valve’s case.

5. Water heater with the mounted valve must be connected to the water

main – install a shut-off valve at the water inlet point. You need to connect

a drain pipe to the opening of the pressure relief of safety valve. Next you

should put a drain pipe to the sewer.
6. Connect the desired number of consumption points to the outlet nozzle,

marked red.
7. Check leak integrity of joints: open the shut-off cock and one of the cock

assemblies. After the tank is filled with water, as evidenced by issue of water

from the cock assembly, shut the cock assembly and check the leak integrity

of all joints.

NOTE:

Do not mount additional accessories, such as a shut-

off valve, between the relief valve and the inlet nozzle.

NOTE:

The water heater is the appliance, operating in such

a manner that pressure of water in the water heater

corresponds to the pressure of water in water main.

If pressure in the main exceeds 0.7 MPa, then it is

necessary to mount a pressure reducer before the

water heater so that pressure doesn’t exceed 0.7MPa.

Connection to electric main

IMPORTANT!

Prior to connecting the tank water heater, make sure

that the water heater is properly grounded. Proper

grounding is important to minimize electric shocks

and risk of fire. The power cord is equipped with a plug

with a grounding pin. The appliance must be used

with a properly grounded power outlet. If the outlet,

you are intending to use, is not properly grounded or

grounded by a time-delay fuse or a circuit breaker,

contact a qualified electrician to install a proper outlet.

1. The water heater is designed to be connected to 230V single-phase

electric main. Prior to connecting make sure that parameters of the electric

main in the place of connection correspond to parameters, specified on the

identification plate with technical parameters of the appliance. You should

follow the current electrical safety code when installing the water heater.
2. The power outlet must be properly grounded. The outlet must be

designed for rated current not less than 10A. The power outlet and plug

must always be dry to prevent current leakage. Regularly check if the

power plug is tightly connected to the outlet. Do it in the following order:

insert the power plug into the outlet, switch off the water heater after half-

hour operation and unplug the cord, check if the plug is heated by your

hand. If the plug is heated over 50°C, then to prevent damages, accidents

and fire as a result of bad electrical contact, replace the outlet with a new

one. A specialist must do this.
3. Power cord of the appliance is a single unit with GFCI (Ground Fault

Circuit Interrupter).

IMPORTANT!

If water in the installation location contains a large

amount of calcium, manganese or iron salts, then

IT IS NECESSARY to mount a respective filter in

the delivery system to reduce the amount of scale

generated in the tank and on the heating element.
