Instructions for use and maintenance

11

EN

English

The connecting of the conductors of the supply cord of the

appliance has to be carried out as follows:

 •

conductor with brown insulation – to the phase

conductor of the electrical wiring (L)

 •

conductor with blue insulation- to the neutral

conductor of the wiring (N)

 •

conductor with yellow-green insulation – to the safety

conductor of the wiring (

)

3.3.

Models without power supply cord

The appliance has to be connected to a separate electricity

circuit of the stationary electrical wiring. The circuit has to

be supplied with a safety fuse 16A. Copper single core (rigid

– non stranded) conductor shall be used for the connection

– cable 3 x 1.5 mm2 for power 2000 W.
The electrical circuit supplying the appliance must have an

in-built device ensuring the splitting of all terminal poles

under conditions of super-voltage of category III.
In order to fix the power cable to the water heater, it is

necessary to remove the plastic cover

(fig.5)

. The power

leads connections must be in accordance with the terminal

markings of the thermal circuit breaker:

 •

the phase cable must be connected to the A1 (11)

terminal

 •

the neutral, to the B1 (21) terminal

 •

and the protection terminal, obligatory to the marked

screwed joint

.

The power supply cord can be fixed to the plastic control

panel with a cable stop. After the installation, the plastic

cover must be replaced in its original position!
Explanations to

Fig.3

:

T1 – thermal regulator, T2 – thermal circuit breaker, IL1 –

light indicator, R – heater

V.

OPERATING THE DEVICE

Before initial start of the device, please make sure that the

water heater has been correctly connected to the electrical

network and that it is filled up with water.
Switching on the water heater is done through the device

incorporated in the installation, which is described in sub-

item 3.2 of paragraph  V, or by inserting the plug into an

electrical socket (for models with cord with a plug).
Clarification to

Fig.6

:

Operation modes:

1.

Position (

) anti-freezing mode

WARNING: The electrical power supply of the device

should be switched on. The safety valve and the pipe

connecting it to the device must be secured against freezing.

2.

Position (

) maximum temperature

3.

Position  (

) at this mode the water temperature

reaches about 60°С. In this way heat losses are reduced.

4.

Light indicator – at heating mode it is lit in red, and it

is lit in blue when the water has been heated up and the

thermostat has switched off.

5.

Regulator knob – for temperature setting

Water heaters with electrical-mechanical POP-UP

operation:

1.

Push the knob to pop-up

Fig. 7а

.

2.

Set the temperature of the water heater

Fig. 7b

This

setting allows for gradual temperature adjustment.

3.

Push the knob to retract

Fig. 7c

 WARNING! Once a month set the knob to the

position ‘maximum temperature’ for a period of 24

hours (unless the device is constantly operated in this mode).

Thus you will ensure better hygiene of the heated water.

VI.

RUST PROTECTION  MAGNESIUM ANODE

The magnesium anode protects the water tank's inner

surface from corrosion. The anode element is an element

undergoing wear and tear and is subject to periodic

replacement. This is cost for the user.
In view of the long-term and accident free use of your water

heater, the manufacturer recommends periodic inspections

of the magnesium anode's condition by a qualified

technician and replacement whenever required, and this

could be performed during the appliance's technical

preventive maintenance.
For replacements, please contact the authorized service

stations!

VII.

PERIODIC MAINTENANCE

Under normal use of the heater, under the influence of high

temperature, lime scale /the so-called lime scale layer/ is

deposited upon the heating element’s surface. This worsens

the heat exchange between the heating element and water.

The heating element’s surface temperature increases along

/of boiling water/. The thermoregulator begins to switch

on and off more frequently. A ‘’deceptive” activation of

the thermal protection is possible. Due to these facts, the

manufacturer recommends preventive maintenance of

your water heater every two years by an authorized service

center or service base. This protective maintenance must

include cleaning and inspection of the anode protector (for

water heaters with glass-ceramic coating), which shall be

replace with a new one if need arises.
In order to clean the appliances use a damp cloth. Do not

clean with abrasive or solvent content detergents. Do not

pour water over the appliance.

The manufacturer does not bare the responsibility

for all consequences caused by not obeying the

instructions, given hereby.

Environmental protection instructions.

Old electric appliances contain prescious

materials and must not be disposed with

the domestic waste! Please make your

active contribution to the protection of the

environment and dispose of the appliance

in the stations organized for the purpose (if

available).
