Instructions for use and maintenance

EN

ATTENTION! In order to prevent injury to user and

third persons in the event of faults in the hot water

supply system, the appliance must be mounted in premises

outfitted with floor hydro insulation and sewer drainage.

Don't place objects, which are not waterproof under the

appliance under any circumstances. In the event of mounting

the appliance in premises without floor hydro insulation, a

protective tank with a sewer discharge drainage must be

placed under the appliance.

Notice: the set does not include a protective tub and the

user must select the same.

2.

Water heater connection to the water supply system

Fig.4a

 - installation scheme above sink

Fig.4b

 - installation scheme under sink

Where: 1 – input pipe, 2 – safety valve (0.8 MPa), 3 –

reduction valve (if the water supply pressure exceeds 0,6

MPa), 4 – stop valve, 5 – bell-mouth discharge to the sewer,

6 – hose;
7 - Drain water tap.
Upon connecting the water heater to the water supply

system, take care of the indicative color markings /rings/ of

the pipes:

BLUE

 -  for cold /in-flowing/ water,

RED

 -  for hot /out-flowig/ water.

The mounting of the safety return-valve supplied with the

water heater is obligatory. The safety return-valve must

be installed on the cold water supply pipe, according to

the arrow stamped on its body that indicates the supplied

water direction.

Exception: If the local regulations (norms) require the

usage of another protection valve or mechanism (in

accordance with EN 1487 or EN 1489), then it must be bought

additionally. For mechanisms operating in accordance with EN

1487 the announced operational pressure must be no more

than 0.7 MPa. For other protection valves, the pressure at which

they are calibrated must be 0.1 MPa lower than the one

marked on the appliance’s sign. In these cases the safety valve

which the appliance is supplied with should not be used

.

ATTENTION! Other type of stopping armature is not

allowed between the protection return valve (the

protective device) and the appliance.

ATTENTION! Any other /old/ safety return-valves may

lead to a failure of your appliance, therefore they

must be removed.

ATTENTION! Fixing the safety return-valve to threads

longer than 10 mm is not allowed, as it could

damaged the valve and could make the use of your

appliance dangerous.

ATTENTION! The safety valve and the pipe between

the valve and the water heater must be protected from

freezing. During hose draining - its free end must be always

open to the atmosphere (not to be immersed). Make sure that

the hose is also protected from freezing.

The boiler is filled with water by opening the tap on the cold

water supply system and the tap on the hot water mixing

faucet. After the filling process is complete, a constant

stream of water should flow from the water-mixing faucet.

Now you can shut the hot water tap on the mixing faucet.
When you must empty the water heater, you should first cut

it off the power supply.

Draining procedure for boilers designed to be installed

ABOVE SINKS:

1.

First shut the cold water supply valve

2.

Open the hot water valve on the mixing-faucet

3.

The water tap 7 (

fig 4a

) must be opened to drain the

water from water tank. If there is no such tap build in the

pipe line, than the water can be drain directly from inlet

pipe of water tank after when you disconnect it from

water main

IMPORTANT: When draining the boiler, take measures

to prevent damages caused by the flowing water.

Draining procedure for boilers designed to be installed

UNDER SINKS:

1.

Switch the boiler off the power supply network.

2.

Dismantle the connecting water fittings from the

boiler.

3.

Disassemble the boiler from its installation place, turn

it so the pipes point to the floor and pour the water in a

vessel you have prepared for the purpose. Wait until all

the water drains out of the boiler.

In case that the pressure in the water mains is over the value

pointed out in the above paragraph I, then it is necessary

to assemble a pressure reduce valve, otherwise the water

heater would not function properly. The Manufacturer does

not assume any liability for problems arising out of the

appliance’s improper use.

3.

Water heater's electrical connection

(fig.3)

 ATTENTION! Before you switch the power supply,

make sure the appliance is full of water.

3.1.

Models fit with power supply cord combined with

a plug

 shall be plugged in a socket. The boiler can be

disconnected from the power supply by unplugging.

 ATTENTION! The wall-plug must be properly

connected to a separate electrical circle that is

provided with a protector. It must be earthed.

3.2.

Water heaters  fitted with a supply cord without a

plug

The appliance has to be connected to a separate electricity

circuit of the stationary electrical wiring.The connecting has

to be constant- with no plug contacts. The circuit has to be

supplied with a safety fuse (16A) (20A for power > 3700W)

and with inbuilt device to ensure disconnection of all pole

pieces in the conditions of over-voltage from category III.
