Removing the cover

The rating plate and the adjusting screw for flow rate setting
are located under this cover.
1.  Push the cover at the corrugation towards the wall bracket.
2.  Press the cover down at the rear corners until the front

edge lifts.

3.  Remove the cover by pulling forward.

12. Rating plate cover

10

11

Replacing the cover

1.  Push the cover flat towards the wall bracket under the

edges of the water connections.

2.  Press down the front edge of the cover and push it forward

again at the rear edge until it fits.

Rating plate cover

On the inner part of
the cover, you can find
the name of the appli-
cation type (1), as well
as the serial number
(2) and the article
number (3).
