33

For contractors

•฀ Direct฀tap฀instantaneous฀water฀heaters

ADEo 70 WD - Mono-lever mixer tap with changeover bath/hand shower

Part no. 18 39 34

•฀ Universal฀mounting฀frame

Part no. 22 77 01

Comprising:

  –  Mounting frame with

–  electrical wiring.

This assembly creates a gap of 30 mm between the device back panel and the installation wall.

฀ This฀enables฀the฀electrical฀connection฀to฀be฀routed฀over฀uninished฀walls฀at฀any฀point฀behind฀the฀

equipment. This increases the equipment depth by 30 mm. This set reduces the protection to IP 24
(splash-proof).

•฀ Offset฀installation฀set฀for฀uninished฀walls

Part no. 22 77 02

Comprising:

฀ –฀ Universal฀mounting฀frame฀(for฀speciication฀see฀part฀no.฀

22 77 01).

–  Pipe bends for a vertical offset of the device relative to the water connection by 90 mm downwards.

•฀ Pipe฀assembly,฀replacement฀of฀a฀gas฀ired฀water฀heater

Part no. 22 77 03

Comprising:

฀ –฀ Universal฀mounting฀frame฀(for฀speciication฀see฀part฀no.฀

22 77 01).

  -  Pipe bends for the installation with existing gas water heater connections

(cold water on the left and DHW on the right).

•฀ Automatic฀maximum฀demand฀controller฀LR฀1-A

Part no. 00 17 86

Priority control of the instantaneous water heater when operating, for example, electric storage heaters

simultaneously. For connection of the LR 1-A, see

L

.

8.

Special accessories
