26

Only trained and authorised experts must install the device and make the electrical connection under full
observance of these installation instructions.

2.1

Equipment layout

A

-

N

1 Output selector

12 Heating system

2 Device cap

13 Type plate

3 Lower section, back panel

14 Mounting bracket

4

DHW฀compression฀itting

15 Stud for mounting bracket

5

Cold฀water฀compression฀itting

16 Cable grommet (power cable from above/below)

6 Top, back panel

17 Twin nipple (cold water with shut off valve)

7 Power switch unit

18 Flat packing

8 Safety pressure limiter (AP 3) with reset

button

19

Screws/rawl฀plugs฀for฀ixing฀the฀back฀panel฀

in฀case฀of฀water฀connection฀on฀inished฀walls

9 Mains terminal

20 Installation template

10 Knock-out for power connection from above

21 Installation and operating instructions

11 Fixing toggle

22 Sieve
23 Support panel (only when installing taps for

inished฀walls)

2.2

Brief description

This hydraulically regulated instantaneous water heater is a pressure device for the heating of cold water to
DIN 1988 that can supply one or several draw-off points.

The PinControl throughput control unit compensates for fluctuations in pressure and thus achieves largely

stable฀temperatures.฀The฀PinControl฀limits฀the฀throughput฀and฀thus฀ensures฀a฀suficient฀rise฀in฀the฀DHW฀

temperature - even in winter.
The hydraulic control system regulates the electrical output automatically in two output stages, subject to the

throughput฀(see฀Table฀2฀"Speciication").

The bare wire heating system is enclosed within a pressure-tested plastic jacket. The heating system is also
particularly suitable for water with low limescale or with limescale content (see Table 3 "Application areas").

2.3

Important information

•฀

Air in the cold water supply can destroy the bare wire heating system inside the equipment or can trip

the safety system. If the water supply to the instantaneous water heater has been interrupted, e.g.
because of a risk of frost or work on the water system, take the following measures prior to taking the
equipment back into use:

1.฀ Remove฀fuses฀or฀trip฀the฀appropriate฀MCBs.
2.฀ Repeatedly฀open฀and฀close฀a฀tap฀downstream฀of฀the฀equipment฀long฀enough฀to฀vent฀all฀air฀from฀

the equipment and its cold water supply line upstream.

3.฀ Replace฀the฀fuses฀or฀reset฀the฀relevant฀MCBs.

•฀

Taps/valves

–  Direct draw-off tap for instantaneous water heater ADEo 70 WD - mono-lever mixer with bath/

฀ hand฀shower฀changeover,฀part฀no.฀18฀39฀34.

–  Installation with commercially available mains pressure taps is possible.
–  Thermostatic pressure valves must be suitable for hydraulically controlled instantaneous water

฀ heaters฀(see฀also฀note฀"1.6฀Recommended฀adjustment฀of฀taps/valves").

Note:

In order for the starting volumes (see Table 3) of stages I and II to be reached safely, pressure losses from
the instantaneous water heater, tap/valve, hand shower, shower hose and pipework must be taken into
account during installation.
Typical pressure losses for a shower water volume of 10 l/min:

–  Mono level mixer

0.04 - 0.08 MPa

–  Thermostatic valves

03 - 0.05 MPa

–  Hand shower

0.03 - 0.15 MPa

•฀ Always฀carefully฀observe฀all฀information฀in฀these฀operating฀and฀installation฀instructions.฀These฀contain฀

important information regarding safety, operation, installation and maintenance of this equipment.

For contractors

2.

Installation instructions

!
