For users and contractors

1.5

DHW output

Subject to season, the following maximum mixed water or draw-off capacities result for different cold water
temperatures (see Table 1):

ϑ

1

 =  Cold water inlet temperature

ϑ

2

 =  Mixed water temperature

ϑ

3

 =  Outlet temperature.

Available temperature, e.g. for:

Showering,฀washing฀hands,฀illing฀a฀bath฀etc.฀

Kitchen฀sink,฀and฀when฀using฀thermostatic฀valves.

ϑ

2

= 38 °C

ϑ

3

= 60 °C

kW

13.5

18

21

24

kW

13.5

18

21

24

ϑ

1

l/min *

ϑ

1

l/min *

6 °C

6.0

8.0

9.4

10.7

6 °C

3.6

4.8

5.6

6.4

10 °C

6.9

9.2

10.7

12.3

10 °C

3.9

5.2

6.0

6.9

14 °C

8.0

10.7

12.5

14.5

14 °C

4.2

5.6

6.5

7.5

Table 1
* Table values relative to a rated voltage of 400 V. The outlet volume is subject to the available supply pressure
and the available mains voltage.

1.6

Recommended valve settings

Twin lever tap

Partial load





  on a basin.

Full load

  

  for a bath, shower or sink.

Add cold water via the twin lever tap, if the temperature is too high and the valve is fully open.

Mono-lever tap

Full load



–  Turn the tap lever fully towards "Hot".
–  Fully open the valve.
–  Raise the temperature by slowly closing the valve.
–  Reduce the temperature by admixing cold water or, if possible, by opening the valve further.

1.7

First aid in case of faults

•฀

Check all fuses.

•฀

Check taps/valves and shower heads for scaling or contamination (see also "6. Troubleshooting").

Where a contractor is required, he can better and more speedily remedy the fault if you provide him with
some of the details from the type plate (

A

 13):

DDLT PinControl . . .  No.:   . . .

-   . .   -

1.8

Maintenance and care

Maintenance work, e.g. checking the electrical safety, must only be carried out by a qualified contractor.

A฀damp฀cloth฀is฀suficient฀for฀cleaning฀the฀casing.฀Do฀not฀use฀abrasive฀or฀corrosive฀cleaning฀agents.

1.9

Operating and installation instructions

Keep these instructions safely and pass them on to any new user, should the equipment change hands.
Let your contractor check their content in conjunction with any maintenance or repair work.

!

!
