EN - 12

4.  USE OF PRODUCT

4.1 Control of hob

The hob is controlled by the pressing the

appropriate electronic button. Each button

press is followed by a buzzer sound.

1

7

8

9 10

11

12 13 14

2

3

4

5

6

1-

 Heater display

2-

Activate/Deactivate heater

3-

Timer display

4-

 Timer function cooking zone indicators

5-

 Triple zone indicator

6-

 Dual zone indicator

7-

 Dual/triple zone selection

8-

Heat setting/timer decrease

9-

 Activate/Deactive timer

10-

Heat setting/timer increase

11-

 Decimal point

12-

 Key lock indicator

13-

Key lock

14-

 On/Off

Mode Descriptions

Stand-By-

Mode

S-Mode

Mains supply is applied

to the hob control and all

heater displays are off or

a residual heat display is

active.

Operating-

Mode

B-Mode

At least one heater display

shows a heat setting

between ´

0

` and ´

9

`.

Lock Mode

VR-

Mode

The hob control is locked.

Turn on and Turn off the Appliance

If the appliance is in Stand-By mode, it is

put in Operating mode by pressing the On/

Off button   for at least 1 second. A buzzer

sound indicates the successful operation .

On all heaters a “

0

” will appear and all

decimal points of the heaters will flash (1

sec on, 1 sec off).

If there is no operation within 10 sec, the

display of all heaters will turn off.

If the displays are turned off, the heater will

be sent into Stand-By mode.

If   is pressed for more than 2 seconds (in

Operating mode), the appliance is switched

off and is sent into S-Mode again. The

appliance can be turned off by pressing

 at any time; even if other buttons are

pressed simultaneously.

If there is any residual heat from a heater,

this will be indicated in the corresponding

Heater Display.

Select Heater

If a single heater is chosen with the

corresponding Activate/Deactivate Heater

Button

 the decimal point of the Heater

Display flashes. For the selected heater,

you can set the heat level between 1-9 by

pressing the Heat Setting Buttons   or

.

The buttons must be pressed within 3

seconds, otherwise the heater selection is

erased and heat setting dot will disappear

(decimal point). If there is no further

operation within 10 seconds, the heater

reverts back to S-Mode.

The heat setting can always be changed by

pressing   or

. The available settings

are between 1-9.

Each button operation or each display

change is accompanied by a buzzer sound.

Turn on Dual and Triple Zones

Turn on the dual zone

The activation of the dual zone is carried

out after selecting the desired heater by

pressing

. This is confirmed by a buzzer

sound. At the same time, the corresponding

Dual Zone Indicator illuminates. Touching

for a second time, toggles the status of the

dual zone; it changes from dual zone on to

dual zone off and back again.

The extension zone can only be activated

after a level between 1-9 is set on the basic

zone of the heater.

Turn on triple zone

A dual or triple zone can only be switched

on if the basic zone of a heater is set to

a level beyween 1–9 and the heater is

selected (this is indicated be the dot being

illuminated).

If   is pressed, the signal sounds and the

Dual Zone Indicator is illuminated. If

 is

pressed once again, there is another buzzer

and the triple heater is switched on. The

Triple Zone Indicator will be illuminated and

the triple zone will be energized.

Pressing

 again will switch off the triple

zone of the heater. Each operation causes
