hanging the type of gas supply (cont'd)

F

OR THE HOB

 1

BURNER

:

C

H A N G E

T H E

I N J E C T O R S

i n   t h e

following way:
• Remove the supports, and all the bur-
ner caps and heads.
• Using a No.10 spanner, unscrew the
central injector located at the base of the
burner unit (see

)

and using a No. 7

spanner, unscrew the 3 injectors located
a r o u n d   t h e   c e n t r a l   i n j e c t o r   ( s e e

)

around (

Fig. 02).

• Replace the corresponding gas injectors,
in accordance with the positioning of the
injectors and the gas characteristics table
shown at the end of this section . To do
this:
• First screw them in manually until the in-
jector locks into place.
• Apply the corresponding spanner to the
injector.

• Turn the spanner clockwise

.

• Replace the head of the burner, the cap
and the grill.
•

C

ONNECT

the electrical cable from the

hob to your single phase mains supply
(220-240V

˜

).  Please refer to the

“Electri-

cal connection”

paragraph.

B

A

●

C h a n g i n g   f r o m   n a t u r a l   g a s   t o

butane/propane gas (cont'd).

Y

OUR HOB IS NOW READY TO OPERATE ON BUTANE

/

PROPANE GAS

.

The easy way to install your hob

49

Tip

- Each time you change the gas supply,

tick the box corresponding to the new gas

level on the label which can be found in the

plastic bag.

Refer to the corresponding “Gas

Connection” section.

B

A

Fig. 2

Warning

Screw on the adaptor with a torque not
exceeding 4 N.m.
Exceeding this limit may damage the
product.
