To make sure that nothing can get
between the frame and the worktop,

s t i c k   t h e   f o a m   s e a l

a r o u n d   t h e

outside of the hob.

Fix in place the joint provided in the
folder before installing the hob :

1-

Remove the pan support grates,

t h e   b u r n e r   c a p s   a n d   h e a d s   a f t e r
checking their position.

2

- Turn the hob over and place it very

carefully over the opening in the unit
taking great care not to damage the
ignition spark qgenerators.

3

- Stick the foam seal supplied with

the appliance

around the outside of

the hob

. This seal prevents anything

g e t t i n g   b e t w e e n   t h e   g l a s s   a n d   t h e
worktop.

4

-   P u t   t h e   b u r n e r s ,   c a p s   a n d   p a n

grates back into position.

I

NSTALLATION OVER A UNIT WITH DOORS

OR DRAWERS

(please see the diagram

opposite).

The installation of your hob over an
oven requires the latter to be in the
low position.
You are advised not to install your hob
over an oven for which ventilation is
not via the front.
You should leave an air inlet of 40 sq.
cm in the right or left wall of the oven
unit.

F

itting recommendations (cont'd)

Seal

Mini 4mm

Gas hob

100 mm

mini

Worktop

Mini 40 cm

2

The hob's heat-safety features
prevent it being used while it is
in pyrolysis mode.

The easy way to install your hob
