H05V2V2F - T90

Cross section of
conductors in

sq. mm

Fuse

220-240 V

~

- 50 Hz

3 conductors of

which 1 is to be

earthed

1

10 A

C

ROSS SECTION OF CABLE TO USE

The easy way to install your hob

This hob must be connected to a 220-
2 4 0   V

~

s i n g l e   p h a s e   m a i n s

supply via a 2-pin + earth plug (CEI
60083 standard) or an all-pole cut-off
device that complies with current ins-
tallation regulations.

The unit must be installed so that the
mains plug is easily accessible.

Warning :
I f   t h e   p o w e r   c a b l e   i s
d a m a g e d ,   i t   m u s t   b e   r e p l a c e d
b y   a   c a b l e   o r   a   s p e c i a l   k i t
a v a i l a b l e   f r o m   t h e
m a n u f a c t u r e r   o r   i t s   A f t e r -
S a l e s   S e r v i c e   D e p a r t m e n t .

E

lectrical connections

The protective conductor is connected to the

earth connection on the hob

and therefore must also be connected to an external earth connection

.

If the power supply cable is damaged, it must be replaced with a cable or a special
unit available from the manufacturer or his After Sales Service.

●
