G

as connections (Cont'd)

●

Possible connections

B

O T T L E D O R T A N K G A S

(

B U T A N E

/

PROPANE

).

For the user's safety, we advise that
you make the connection usint a rigid
p i p e   i f   t h i s   i s   p o s s i b l e ,   o r   w i t h   a
reinforced, braided, flexible gas hose
(maximum length 2 metres)

(fig. A)

.

For an existing installation,

where

it is not possible to fit a reinforced,
b r a i d e d ,   f l e x i b l e   g a s   h o s e ,   t h e
c o n n e c t i o n   c a n   b e   m a d e   w i t h   a
flexible gas hose (maximum length
2 metres),

with two jubilee clips

:

one on the connector

(fig. B)

, and the

other on the pressure regulator, and a
s e a l   s h o u l d   b e   f i t t e d   b e t w e e n   t h e
connector and the elbow seal on the
hob.

You can obtain the adaptor and seal
from your After-Sales Service Depart-
ment.

BUTANE/PROPANE
Pressure regulator compulsory

propane

butane

ne

propane

Temperatures above 30°C would cause overheating of the gas hose. To

avoid this, check that there are no heat-producing devices nearby.

Screw on the adaptor with a torque not exceeding 25 N.m.

In France, you must use a hose or a pipe bearing the stamp NF Gaz.

Seal
(not provided)

Jubilee clip
(not provided)

Jubilee clip
(not provided)

;

;

@

@

;

;

Q

Q

fig. A

fig. B

Reinforced,

braided, flexible

gas hose with

threaded

connectors

Flexible hose

connection

propane
