Simfer H30I12B011 - Инструкция по эксплуатации - Страница 12

12

GB

in concurrent alternation with [0].
 After the device is turned off, the indicator will remain black and [H] will

be shown as an optical warning for the hot cooking surface.

Turning off all Cooking Surfaces:

Turning off all cooking surfaces at once is always possible by using the

ON/OFF button. [H] will possibly be seen in all hot cooking surfaces. The

screens of all other cooking surfaces will remain black.

Pause (Optional)

Activating the pause function;
Heating elements may be turned off by pressing a special button as-

signed for ‘‘>=1’’ second while at least one cooking surface is operating.

The pause condition may also become activated with specific errors in the

cooking surface – here the error indication is hidden. The idle temperature

indicator; and such specific messages as A, P, or no pan are also hidden.

The  pause  screen  will  be  in  the  first  order  of  priority.  General  errors  will

prevent the control from being turned off and the pause function from

being activated. If a general error takes place during pause the control will

be turned off and the pause mode will be terminated.

During the Pause Function

Only ‘‘RHE’’ cookers will only terminate the ‘‘PWM’’ output relay with the

aim of protecting all conditions throughout the pause stage. Thus, all re-

lays will drop at the same time (for instance, the all polar termination relay

in the pause function does not have a time-delay). The ‘‘μC’’ output pins

of the timer relays will still be triggered according to the task cycle of the

selected cooking surface (-> influence on the idle temperature algorithm).

The power requirements of induction and combined selections are ad-

justed to 0% at the ‘‘LIN’’ level throughout the pause function and they

will return to the internal cooking stage of the touch-screen control follow-

ing termination.

Important:

 If the delay time of the power reduction of the pause function

is activated for a period of 83 seconds), ‘‘SW’’ may not be reconfigured to

the last setting of the user as required to be realized in priority following
