Monsher MHE 33 - Инструкция по эксплуатации - Страница 21

21

English

Under any circumstances, make sure the ceramic cooker hob is well ventilated

and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in
good work state. As shown below.

Note: The safety distance between the hotplate and the cupboard above the hotplate should be
at least 760mm.

A (mm)

B (mm)

C (mm)

D

E

760

50 mini

20 mini

Air intake

Air exit 5mm

WARNING: Ensuring Adequate Ventilation

Make sure the ceramic hob is well ventilated and that air inlet and outlet are

not blocked. In order to avoid accidental touch with the overheating bottom of the
hob, or getting unexpectable electric shock during working, it is necessary to put a
wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom
of the hob. Follow the requirements below.

Min. 30 mm

Max. 5 mm

Max. 5 mm

Min. 50 mm
