Operating light

The operating light illuminates green as soon as the
unit is switched on. If the water base is taken off
the base, the green LED changes to red and unit
operation is interrupted, but the unit is not current-
less. Only when the water base is returned to the
base does the red LED turn green again and the unit
resumes operation.

Power rating plate

The following information is displayed on

the power rating plate:

Product name
Electrical voltage
Power consumption
Protection class
Production number
Production date

Mark of conformityThe data on the power rat-
ing plate in the illustrations is only exemplary.
Please check the data on the power rating plate
of your unit.

Functional principle

When filling the unit, the float switch is lifted with
the water gauge. When the water gauge reaches the
water capacity fill line, the float tip closes the fill-
ing opening of the unit. The evaporator wick soaks
up water. The fan pushes the dry room air through
the moist mat and emits it as sufficiently moistur-
ized air. Through the directed guiding of the airflow,
nearly constant humidification is possible at every
water level. Therefore the unit creates optimum
air moisture, without additional control units being
necessary.

Ionic Silver Stick

®

 for water quality mainte-

nance

The specially adapted anti-microbial protec-

tion system Ionic Silver Stick

®

 prevents microbial

growth in the water in the water base. Therefore no
chemical additives are necessary for water quality
maintenance.
The Ionic Silver Stick

®

 is self-renewing, service free

and can be used for a year.

Lifecycle indicator

The unit is equipped with a lifecycle indica-

tor for the Ionic Silver Stick

®

. Please cross off the

current month on the label and write the current
year on the line provided.

Unpacking the unit

At delivery the unit is completely assembled and
already equipped with an evaporator wick.

The float body (styrofoam) is a component of
the float assembly and does not belong to the
packaging.

•
•
•
•
•
•

•

B 14

B 14

Functional principle

B 4

B 4

B 9

B 9

Unpacking the unit

CAUTION

Risk of injury by falling parts!

Always handle the unit by the base when un-
packing and lifting.

Ⴇ

CAUTION

Damage to the unit due to removal of the float
body (styrofoam)!

Do not remove the float body (styrofoam) when
unpacking the unit.

Ⴇ

Open the packaging.


  Remove the upper part of the styrofoam

packaging.


  Reach into the filling opening and grasp

the upper end of the plastic bag securely.


  Carefully pull the plastic bag with the unit

out of the packaging. When doing so, grasp the
plastic bag securely and do not let go of the plas-
tic bag when removing.


  Place the plastic bag with the unit on the

floor and push the plastic bag down along the
unit.


  Hold the unit by the base and lift up out of

the plastic bag.
All packaging components as well as the plastic
bag are removed from the unit.


  Check data regarding the power supply

on the power rating plate.


  Check that all components of the unit are

included.

Putting the unit into operation

Positioning the unit

CAUTION

Damage to the plastic due to high tempera-
tures!

Do not expose the unit to temperatures > 50 °C.

Ⴇ

Observe the following pointers when positioning the
unit:

Remember to ensure easy accessibility

and sufficient room for servicing and cleaning
the unit.
Only operate the unit when it is filled!

Place the unit on the floor or on a flat, dry surface
in the room.
Fill the unit (see chapter "Filling the unit").

Filling the unit

There are the following possibilities for filling the
unit with water:

using the filling opening on the upper part or
directly into the removed water base from a fau-
cet.

There are no foreign objects in the unit.


  The unit is assembled properly.

After an extended period of disuse, the unit
should be emptied and cleaned. Before recom-
missioning, ensure that the unit is clean. Other-
wise an unpleasant odor can result.

1.
2.

3.

4.

5.

6.

ᇒ

7.

8.

•

•

1.

2.

•
•

ᅛ
ᅛ

C 1

C 1

C 2

C 2

C 3

C 3

C 5

C 5

C 6

C 6

B 14

B 14

B

B

Putting the unit into operation

A 14

A 14

B

B

Technical data

Value

Electrical voltage

230 V/50 Hz

Power consumption

20 W

Humidity output

up to 220 g/h

Suitable for rooms

up to 40 m²

Water capacity

max. 3.8 l

min. 0.2 l

Dimensions LxWxH

320 x 320 x 400 mm

Weight (empty)

3.8 kg

Operation noise level

< 25 dB(A)

Description of the unit

The unit consists of the following components:

Filling

opening

Top

assembly

 Float assembly (B 16–19)

 Ionic Silver Stick

®

 (ISS)

 Water base (B 5–7)

 Water capacity fill line

Base

handles

Spout

 Lifecycle indicator for the Ionic Silver

Stick

®

 (ISS)

Power

cord/plug

 Base (B 11–14)

Fan

 Slide switch (B 20–21)

 Power rating plate (on the underside of

the unit)

The float assembly consists of the following parts:

Float

tip

 Water level indicator ring (max. 3.8 l)

Evaporator

wick

A7018

Float

basket

 Float body (styrofoam)

The slide switch consists of the following parts:

Slide

switch

Operating

light

Operating modes

The following operating modes can be set on the
slide switch:

Position Function

0

The unit is switched off

I

The unit is operating in night mode
(low noise level)
The operating light turns green

II

The unit is operating in normal mode
(maximum humidity output)
The operating light turns green

•
•
•
•
•
•
•
•
•

•
•
•
•
•

•
•
•
•
•

•
•

Technical data

Description of the unit

B 1

B 1
B 2

B 2
B 3

B 3
B 4

B 4
B 5

B 5
B 6

B 6
B 7

B 7
B 8

B 8
B 9

B 9

B 10

B 10
B 11

B 11
B 12

B 12
B 13

B 13
B 14

B 14

B 15

B 15
B 16

B 16
B 17

B 17
B 18

B 18
B 19

B 19

B 20

B 20
B 21

B 21
