CAUTION: Do not mix fuel for more than 1

month at a time.

To add fuel

• Always use a fuel container with an antispill valve.
• If there is some fuel on the container, remove the

unwanted fuel and let the container dry.

• Make sure that the area near the fuel tank cap is

clean.

• Shake the fuel container before you add the fuel

mixture to the fuel tank.

To do a run-in

• During the first 10 hours of operation, do not apply

full throttle without load for extended periods.

To start and stop

To examine before start

1. Make sure that the product has no missing,

damaged, loose or worn parts.

2. Make sure that nuts, screws and bolts are tightened.
3. Make sure that the blades or trimmer head is not

damaged.

4. Make sure that the locknut is tightened. Refer to

To

examine the locknut on page 18.

5. Make sure that the air filter is not clogged.
6. Make sure that the safety devices on the product is

not defective.

7. Make sure that the product has no fuel leaks.

To adjust the harness

WARNING: The product must always be

correctly attached to the harness. Do not

use a defective harness.

1. Put on the harness.
2. Connect the product to the harness.
3. Adjust the harness for the best work position.
4. Adjust the side straps to make the product weigh

equally on your shoulders. (Fig. 34)

5. Adjust the harness until the cutting attachment is

parallel to the ground.

6. Let the cutting attachment lightly touch the ground.

Adjust the harness clamp to balance the product

correctly.

Note: If you use a grass blade, it must balance

approximately 10 cm /4 in above the ground.

To start a cold engine

1. Push the air purge bulb 10 times. (Fig. 35)

2. Pull the choke control up. (Fig. 36)
3. Hold the body of the product on the ground with your

left hand. (Fig. 37) Do not step on the product. Pull

the starter rope handle slowly until you feel some

resistance. Then pull the starter rope handle with

force.

Note: Do not pull the throttle trigger while you start

the engine.

4. Continue to pull the starter rope handle until the

engine starts or tries to start (max. 3 pulls). If the

engine starts or tries to start, push the choke control

down. Continue to pull until the engine starts. Wait

60 seconds after a start before you pull the throttle

trigger.

CAUTION: Do not pull the starter rope

until it stops. Do not let go of the starter

rope when it is fully extended. Release

the starter rope slowly. Failure to obey

these instructions can cause damage to

the engine.

To start a warm engine

1. Push the air purge bulb 10 times.
2. Pull the starter rope until the engine starts.

To start the engine when the fuel is too hot

If the product does not start, the fuel can be too hot.

Note: Always use new fuel and decrease the operation

time during warm weather.

1. Put the product in a cool area away from open

sunlight.

2. Let the product cool down for 20 minutes at

minimum.

3. Press the air purge bulb again and again for 10-15

seconds.

4. Obey the procedure to start a cold engine. Refer to

To start a cold engine on page 16.

To stop

• Push the stop switch to stop the engine. (Fig. 21)

Note: The stop switch automatically goes back to its

initial position.

To operate the grass trimmer

CAUTION: Make sure that you slow the

engine to idle speed after each operation. A

long period at full throttle without a load on

the engine can cause damage to the engine.

Note: Clean the cover of the trimmer head when you

attach a new trimmer line to prevent vibrations. Examine
