22

 GB

4

 HDMI IN 1 or 2

HDMI 1 or

HDMI 2

Digital video and audio signals are input from the connected

equipment.

In addition, when you connect the equipment that is
compatible with control for HDMI, communication with the

connected equipment is supported. Refer to page 30 to set up

this communication.
If the equipment has a DVI socket, connect the DVI socket to

the HDMI IN 2 socket through a DVI - HDMI adaptor

interface (not supplied), and connect the equipment’s audio
out sockets to the audio in sockets in the HDMI IN 2 sockets.

~

• The HDMI sockets support the following video inputs only:

480i, 480p, 576i, 576p, 720p, 1080i, 1080p and 1080/24p.
For PC video inputs, see page 36.

• Be sure to use an HDMI cable that bears the HDMI logo.
• When connecting an audio system that is compatible with

control for HDMI, be sure to also connect it to the
DIGITAL AUDIO OUT (OPTICAL) socket.

9

 HDMI IN 3

HDMI 3

5

/

PC IN

PC

It is recommended to use a PC cable with ferrites like the

“Connector, D-sub 15” (ref. 1-793-504-11, available in Sony

Service Centre), or equivalent.

6

 DIGITAL

AUDIO OUT

(OPTICAL)

(except for KDL-

40S40xx/40U40xx)

Use an optical audio cable.

7

You can listen to TV sound on the connected Hi-Fi audio

equipment.

8

 CAM

(Conditional

Access Module)

Provides access to pay TV services. For details, refer to the

instruction manual supplied with your CAM.
To use the CAM, remove the “dummy” card from the CAM

slot, then turn off the TV and insert your CAM card into the

slot. When you are not using the CAM, we recommend that
you keep the “dummy” card in the CAM slot.

~

• CAM is not supported in some countries/areas. Check with

your authorised dealer.

0

 AV3,

and

AV3

AV3

When connecting mono equipment, connect to the

AV3 L

socket.

qa

i

Headphones

You can listen to TV sound through headphones.

Connect to

Input symbol on
screen

Description
