English - 1
Sound Control
Changing the Sound Standard
Mode → Standard / Music / Movie / Speech / Custom
You can select the type of special sound effect to be used when watching a
given broadcast.
Press the
TOOLS
button to display
Tools
menu.
You can also conigure the sound mode by selecting
Tools → Sound
Mode
.
Equalizer
The sound settings can be adjusted to suit your personal preferences.
Mode
: You can select a sound mode to suit your personal preferences.
Balance
: Controls the balance between the right and left speakers.
100Hz / 300Hz / 1kHz / 3kHz / 10kHz
(Bandwidth Adjustment): To adjust the level of different bandwidth frequencies
Reset
: Resets the equalizer settings to the default values.
SRS TruSurround XT → Off / On
TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers.
TruSurround delivers a compelling, virtual surround sound experience through any two-speaker playback system, including
internal television speakers. It is fully compatible with all multichannel formats.
Press the
TOOLS
button to display
Tools
menu.
You can also set the
SRS TruSurround XT
by selecting
Tools → SRS TS XT
.
TruSurround XT
, SRS and
Symbol are trademarks of SRS Labs, Inc.
TruSurround XT
technology is incorporated under license from SRS Labs, Inc.
Audio Language
You can change the default value for audio languages. Displays the language information for the incoming stream.
While viewing a digital channel, this function can be selected.
You can only select the language among the actual languages being broadcast.
Audio Format → MPEG / Dolby Digital
When sound is emitted from both the main speaker and the audio receiver, a sound echo may occur due to the decoding
speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function.
While viewing a digital channel, this function can be selected.
You can only select the language among the actual languages being broadcast.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
Audio Description
This is an auxiliary audio function that provides an additional audio track for visually challenged persons. This function handles
the Audio Stream for the AD (Audio Description), when it is sent along with the Main audio from the broadcaster. Users can
turn the Audio Description On or Off and control the volume.
Audio Description → Off / On
: Turn the audio description function on or off.
Volume
: You can adjust the audio description volume.
Volume
is active when
Audio Description
is set to
On
.
While viewing a Digital channel, this function can be selected.
❑
T
❑
❑
T
❑
N
N
❑
N
N
❑
N
N
Mode
: Custom
►
Equalizer
SRS TruSurround XT : Off
Audio Language
: ----
Audio Format
: ----
Audio Description
Auto Volume
: Off
Select Speaker
: TV Speaker
So
u
n
d
