18

Additional Information

Connecting Additional Equipment

Using the following instructions you can connect a wide range of optional equipment to your TV set.

(Connecting cables are not supplied).

4

4

o

4

4

4

o

4

B

C

A

S VHS/Hi8/
DVC
camcorder

8mm/Hi8/
DVC

camcorder

When you connect the headphones,

the TV speakers will automatically be
muted.

• To avoid picture distortion, do not connect external equipment to connectors

A

 and

B

 at the same

time.

• Do not connect a Decoder to the Scart connector

F

.

Connecting a VCR:

To connect a VCR, please refer to the section “Connecting the aerial and VCR” of this instruction manual. We

recommend you connect your VCR using a Scart lead. If you do not have a Scart lead, tune in the VCR test

signal to the TV programme number “0” by using the “Manual Programme Preset” option. (for details of how

to manually programme these presets, see page 13, step a).

Refer to your VCR instruction manual to find out the output channel of your VCR.

Connecting a VCR that supports Smartlink:

Smartlink is a direct link between the TV set and the VCR. For more information on Smartlink, please

refer to the instruction manual of your VCR.

If you use a VCR that supports Smartlink, please connect the VCR by using a Scart lead to the Scart

socket

3

/

3

G

.

If you have connected a decoder to the Scart

3

/

3

G

 or through a VCR connected to

this Scart:

Select the “Manual Programme Preset” option in the “Set Up” menu and after selecting the “Decoder

**

” option,

select “On” (by using

the

v

 or

V

 button). Repeat this procedure for each scrambled signal.

**

The availability of this option depends on the country you have selected in the “Language/Country” menu.

S

S

*

 “PlayStation”

is a product of Sony

Computer Entertainment, Inc.

*

“PlayStation

” is a trademark of Sony

Computer Entertainment, Inc.

F

G

Decoder

“PlayStation”

*

DVD

D

Hi-Fi

Decoder

VCR

E

continued...
