7

Original instructions

EN

pRIoR to INItIAl opERAtIoN

▪

Make sure power supply voltage corresponds

to the value indicated on the name plate with

technical data of the appliance.

▪

If the supply cord is damaged it must be re-

placed with a special cord or assembly avail-

able from the manufacturer or its service agent

to avoid a safety hazard.

▪

It is absolutely necessary for you to read, under-

stand, and observe the section entitled “Safety

instructions for vacuum cleaners”.

▪

Prior to initial operation the operating staff must

be instructed on the appliance correct usage,

trained and informed on the risks associated

with the material to be picked up and the safe

disposal of the collected material.

Dust class m

filter bag /

Disposal bag /

filter element

Cat. №

Dust with OEL

values

≥ 0.1 mg/m

3

(observe any

additional national

regulations)

Wood dust and

concrete dust

Disposal bag

(5 pcs.)

Cat. №

20009642304

Fleece filter bag

(5 pcs.)

Cat. №

20009642204

PET cartridge filter

(1 pc.)

Cat. №

20009642500

Flat filter

(2 pcs.)

Cat. №

20009642401

sUctIoN poWER coNtRol

The suction power can be adjusted by rotating

the switch lever (4) to allow optimum adaptation to

various operations

(Fig. 10, Fig.11).

DRy vAcUUm clEANING

WARNING:

Never vacuum up hazard

-

ous materials.

Always insert a fleece filter bag or a disposal bag

into the tank prior to dry vacuum cleaning. Thus

the disposal of the vacuumed material is conve-

nient and hygienic.

ImpoRtANt!

The filter element is damp after wet

vacuum cleaning. A damp filter clogs more quickly

when dry vacuum cleaning. For this reason the fil

-

ter should be washed and dried or replaced with a

dry one prior to dry vacuum cleaning.

▪

Make sure that the appliance is not plugged into

the power supply

(Fig.12).

vc 1530sp, vcm 1530sp

 - Remove the upper

section

(Fig.13)

, fit the fleece filter bag (16) into the

tank

(Fig.14a)

 and press firmly its hard carton in

-

sert to the inlet fitting

(Fig.14b)

 taking care not to

damage the fleece filter bag.

vc 1530sA, vcm 1530sA

 - Remove the upper

section

(Fig.13)

 and insert the disposal bag (18)

into the tank (2). Check that the disposal bag ven-

tilation openings

 v

 remain inside the tank and

press  its  hard  carton  insert  firmly  to  the  inlet  fit

-

ting. Fold the top edge of the disposal bag over the

tank rim

(Fig.15)

.

▪

Place the upper section back on the tank and

clip the clamps

(Fig.16)

.

▪

Insert the larger end of the hose into the tank

front inlet and lock in place

(Fig.17)

.

▪

Select the necessary nozzle or aluminium ex-

tension tube (VC 1530SP) and connect it to the

free hose end

(Fig.18)

.

▪

Plug in the vacuum cleaner

(Fig.19)

.

▪ Place the switch (4) to position ″

I

″ to switch the

motor on

(Fig.20)

.

▪

When you have completed vacuuming, switch

the motor off by shifting the switch (4) to posi-

tion ″

o

″ and unplug the cable.

Check the fleece filter bag regularly and replace it

when it is 2/3 full. The filter bag is designed in such

way that only air, and no dust, can pass through

the material. Therefore a used filter bag shall not

be reused.

NotE:

Do not use the fleece filter bag or the dis

-

posal bag for vacuuming up objects with sharp

edges or wet objects.

IMPORTANT!  After  wet  cleaning  the  filter

must be washed and dried or replaced with a

dry one before dry cleaning again.

WARNING:

Never  use  a  fleece  filter

bag or a disposal bag for wet cleaning.

AUtomAtIc moDE WItH poWER tools

▪

Unplug the vacuum cleaner.

▪

Open the clamps (10) and remove the upper

section (7).

▪

Check to make sure that the tank (2) is free of

dust and dirt.
