6

VC 1530SP • VC 1530SA • VCM 1530SP • VCM 1530SA

EN

▪

Children, disabled and aged persons are often

not aware of the dangers that can result from

handling electric appliances. The above men-

tioned groups must never work with this elec-

trical appliance. It is also imperative that you

observe the accident prevention regulations in

force in your area. The same applies for gen-

eral rules of occupational health and safety.

▪

The manufacturer shall not be liable for any

changes made to the appliance nor for any

damage resulting from such changes.

IV - Know your product

  1. Castors

  2. Tank

  3.  Suction hose inlet

  4.   Switch

  5.  Built-in socket

  6.  Operating button for filter cleaning

(VC 1530SP, VCM 1530SP)

  7.  Upper section

  8.   Handle

  9.  Fixing point for suction hose holder

 10.   Clamps

 11.  Electronic alarm

(VCM 1530SP, VCM 1530SA)

 12.  Hose diameter selector switch

(VCM 1530SP, VCM 1530SA)

 13.  Suction hose set

 14.  Aluminium extension  tubes (x2)

(VC 1530SP)

 15.  PET cartridge filter (VC 1530SP)

 16.  Fleece filter bag (VC 1530SP)

 17.  Flat filter x2 (VC 1530SA)

 18.  Disposal bag (VC 1530SA)

 19.  Tool adapter  (VC 1530SP)

 20.  Tool adapter (VC 1530SA)

 21.  Blowing adapter (VC 1530SA)

 22.  Crevice nozzle  (VC 1530SP)

 23.  Combo brush for floors and carpets

(VC 1530SP)

 24.  Brush nozzle  (VC 1530SP)

UNpAcKING

Due to modern mass production techniques, it is

unlikely that your electric appliance is faulty or that

a part is missing. If you find anything wrong, do not

operate the appliance until the parts have been

replaced or the fault has been rectified. Failure to

do so could result in serious personal injury.

▪

Carefully unpack the contents of the box.

▪

Open the clamps (10), remove the upper sec-

tion (7) and take out the contents from the tank

(Fig.1 and Fig.2)

.

▪

Please check the parts using the list shown

above to make sure they are complete and that

there has been no damage in transport.

AssEmbly

▪

Make sure that the cable is unplugged

(Fig.3)

.

▪

Open the clamps and remove the upper section

(Fig.4)

.

▪

For dry vacuum cleaning use the fleece fil-

ter bag (VC 1530SP) or the disposal bag

(VC 1530SA).

vc 1530sp, vcm 1530sp

 - Place the fleece filter

bag (16) into the tank (2)

(Fig.5a)

 and press its hard

carton insert firmly to the inlet fitting

(Fig.5b)

.

vc 1530sA, vcm 1530sA

 - Insert the disposal

bag (18) into the tank (2). Check that the disposal

bag ventilation openings

v

 remain inside the tank

and press its hard carton insert firmly to the inlet

fitting. Fold the top edge of the disposal bag over

the tank rim

(Fig.6)

.

▪

For wet vacuum cleaning use the PET car-

tridge filter (VC 1530SP) or both flat filters

(VC 1530SA).

vc 1530sp, vcm 1530sp

 - Insert the PET car-

tridge (15) into the upper section (7). Fit the filter

holder and turn it clockwise to secure it

 (Fig.7)

.

vc 1530sA, vcm 1530sA

  -  Insert  both  filter  el

-

ements (C) into the cassettes (D) and attach the

cassettes onto the upper section and fix them with

the tensioner (B)

(Fig. 8)

.

▪

Attach the upper section back on the vacuum

cleaner and close the clamps

(Fig.9)

.

V - Operation instructions

This electric appliance is supplied from single-

phase alternating current mains only. The vacuum

cleaner must be connected to grounded sockets.

This electric appliance is radio suppressed in

compliance with EMC Directive 2004/108/EC.
This electric appliance is designed to vacuum the

dust generated during operating a power tool. For

this purpose the vacuum cleaner is equipped with

a built-in socket (5), for inserting the cable plug of

the power tool. The vacuum cleaner will switch

on automatically as soon as you switch on the

power tool. When you switch off the power tool,

the vacuum cleaner will also switch off after a pre-

set delay.
