OPERATION

NOTE:

The drill will not run unless the rotation selector is

pushed fully to the left or right.
Avoid running the drill at low speeds for extended periods
of time. Running at low speeds under constant usage
may cause the drill to become overheated. If this occurs,
cool the drill by running it without a load and at full speed.

INTERNAL SPINDLE LOCK

The internal spindle lock allows the user single-handed
control of chuck adjustments and bit changes. Squeezing
the chuck body stops the chuck jaws from turning. For
bit changes and chuck adjustments, squeeze the chuck
body and turn.

KEYLESS CHUCK

See Figure 5.

The drill has a keyless chuck to tighten or release drill
bits in the chuck jaws. The arrows on the chuck indicate
which direction to rotate the chuck body in order to

LOCK

(tighten) or

UNLOCK

 (release) the drill bit.

WARNING

Do not hold the chuck with one hand and use the
power of the drill to tighten the chuck jaws on the
drill bit. The chuck body could slip in your hand,
or your hand could slip and come in contact with
the rotating drill bit. This could cause an accident
resulting in serious personal injury.

TWO-SPEED GEAR TRAIN (HI-LO)

See Figure 6.

The drill has a two-speed gear train designed for drilling
or driving at

LO (1)

 or

HI (2

) speeds. A slide switch is

located on top of the drill to select either

 LO (1)

 or

HI (2)

speed. When using drill in the

LO (1)

 speed range, speed

will decrease and unit will have more power and torque.
When using drill in the

HI (2)

 speed range, speed will

increase and unit will have less power and torque. Use

LO (1)

 speed for high power and torque applications and

HI (2)

 speed for fast drilling or driving applications.

NOTE:

  If you have difficulty changing from one gear

range to the other, turn the chuck by hand until the gears
engage.

CAUTION:

Never change gears while the tool is running.
Failure to obey this caution could result in serious
damage to the drill.

QUICK MODE SELECTOR

See Figure 7.

The Quick Mode Selector allows you to quickly switch
from drill mode to drive mode.
In general, drill mode should be used for drilling and
other heavy duty applications. Drive mode should be
used for driving screws.percussion mode should be used
for impact drilling.

SELECTING DRIVE OR DRILL SETTING

See Figure 6-7.

Using the chart below, choose correct speed and mode
the type of bit, fastener, and material you will be using.

■

Choose your

 APPLICATION

■

Choose the correct

 SPEED: (1/LOW or 2/HIGH)

■

Choose the correct

 MODE: (DRIVE, DRILL, OR

HAMMER)

1. APPLICATION

2. SPEED

3. MODE

• Lag screws up to 9.5 mm dia. by 38.1 mm long
• Hole saw up to 50.8 mm
• Spade bits up to 38.1 mm
• Drill bits up to 12.7 mm
• Drilling into metal
• Concrete screws

1/LOW

DRILL MODE

(TORQUE ADJUSMENT NOT ACTIVE)

2/HIGH

• Drill bits up to 6.4 mm
• Deck or wood screws up to 63.5 mm long
• Self tapping screws

1/LOW

DRIVE MODE

• Deck or wood screws up to 63.5 mm long
• Small screws or delicate work that requires more control

2/HIGH

• Masonry bit up to 12.7 mm

1/LOW

HAMMER MODE

(TORQUE ADJUSMENT NOT ACTIVE)

2/HIGH
