6

ENGLISH

Switch action

1

1. Switch trigger

CAUTION:

Before inserting the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

To start the tool, simply pull the switch trigger. Tool

speed is increased by increasing pressure on the switch

trigger. Release the switch trigger to stop.

Electric brake

This tool is equipped with an electric brake. If the tool

consistently fails to quickly stop after the switch trigger

is released, have the tool serviced at a Makita service

center.

Lighting up the front lamp

1

1. Lamp

CAUTION:

Do not look in the light or see the

source of light directly.

Pull the switch trigger to light up the lamp. The lamp

keeps on lighting while the switch trigger is being pulled.

The lamp goes out 10 -15 seconds after releasing the

trigger.

NOTE:

 Use a dry cloth to wipe the dirt off the lens of

the lamp. Be careful not to scratch the lens of lamp, or

it may lower the illumination.

Reversing switch action

1

A

A

A

B

1. Reversing switch lever

CAUTION:

Always check the direction of

rotation before operation.

CAUTION:

Use the reversing switch only after

the tool comes to a complete stop.

 Changing the

direction of rotation before the tool stops may dam-

age the tool.

CAUTION:

When not operating the tool,

always set the reversing switch lever to the neu-

tral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun-

terclockwise rotation.

When the reversing switch lever is in the neutral posi-

tion, the switch trigger cannot be pulled.

Speed change

1

1. Speed change lever

CAUTION:

Always set the speed change lever

fully to the correct position.

 If you operate the

tool with the speed change lever positioned halfway

between the "1" side and "2" side, the tool may be

damaged.

CAUTION:

Do not use the speed change lever

while the tool is running.

 The tool may be damaged.
