14
Long lasting operation at low rotational speed of the spindle may
cause motor overheating. Make periodic breaks in operation or allow
the tool to operate at top speed without load for approximately 3
minutes.
HOLDER
The power tool provides convenient holder (
6
) that allows to e.g.
hang the tool on a tool belt when working at heights.
OPERATION AND MAINTENANCE
MAINTENANCE AND STORAGE
•
Cleaning the device after each use is recommended.
•
Do not use water or any other liquid for cleaning.
•
Clean the power tool, battery and charger with a dry cloth or blow
through with compressed air at low pressure.
•
Do not use any cleaning agents or solvents, they may damage
plastic parts.
•
Clean ventilation holes in the motor casing regularly to prevent
device overheating.
•
In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a qualified
person.
•
Store the power tool and its equipment in a dry place, beyond
reach of children.
•
Store the device with the battery removed.
All defects should be repaired by service workshop authorized by
the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless impact driver 58G024
Parameter
Value
Battery voltage
18 V DC
Max. torque (gear I / II / III)
80 / 120 / 200 Nm
Range of spindle rotational speed
without load (gear I / II / III)
0-1000 / 0-1800 / 0-2700 rpm
Range of impact rate (gear I / II / III) 0-1400 / 0-2520 / 0-3780 min
-1
Tool holder
Hexagonal 6.35 mm (¼")
Protection class
III
Weight
1.1 kg
Year of production
2020
58G024 defines type and indication of the device
Graphite Energy+ System Battery
Parameter
Value
Battery
58G001
58G004
Battery voltage
18 V DC
18 V DC
Battery type
Li-Ion
Li-Ion
Battery capacity
2000 mAh
4000 mAh
Ambient temperature range
4
0
C – 40
0
C
4
0
C – 40
0
C
Charging time for charger 58G002
1 h
2 h
Weight
0,400 kg
0,650 kg
Year of production
2020
2020
Graphite Energy+ System Charger
Parameter
Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2020
NOISE LEVEL AND VIBRATION PARAMETERS
Noise and vibration information
Parameters of produced noise level, such as sound pressure level
Lp
A
and sound power level Lw
A
with measurement uncertainty K are
specified below in this manual, in compliance with EN 60745.
Vibration values a
h
and measurement uncertainty K are determined
in accordance with EN 60745-2-2 and specified below.
Vibration level specified below in this manual was measured in
accordance with measurement procedure defined in EN 60745 and
can be used to compare power tools. It can also be used for initial
assessment of exposure to vibrations.
Specified vibration level is representative for main applications
of the power tool. Vibration level may change if the power tool is
used for other purposes, with different working tools or will not
be maintained properly. The abovementioned factors may lead to
higher exposure to vibrations during whole working time.
To precisely define exposure to vibrations, include periods when the
power tool is switched off and when it is switched on but not used for
working. This way total exposure to vibrations may be significantly
lower. Use additional safety measures to protect the user against
results of exposure to vibrations, such as: power tool and working
tool maintenance, proper hand temperature conditions, good work
organisation.
Sound pressure level: Lp
A
= 69 dB (A) K=3dB (A)
Sound power level: Lw
A
= 80 dB (A) K=3dB (A)
Vibration acceleration: a
h
= 3,845 m/s
2
K = 1,5 m/s
2
ENVIRONMENTAL PROTECTION
Electrical equipment must not be disposed off
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.
Li-Ion
Storage batteries/batteries must not be disposed
with domestic waste, put in a fire or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.
* Right to introduce changes is reserved.
