12

•

Always keep the battery away from sources of heat. Do not leave

the battery for a long time in high temperature (in direct sunlight,

in proximity of heaters and wherever the temperature exceeds

50°C).

 • Do not expose the battery to fire or excessive temperature.

Exposure to fire or temperature above 130°C may cause explosion.

CAUTION!

 Temperature of 130°C can be also defined as 265°F.

 • Observe all charging instructions. Do not charge the battery

in temperature outside of range defined in the rating data

table from the instruction manual.

Incorrect charging or

charging in temperature outside of defined range may damage the

battery and increase the risk of fire.

BATTERY REPAIRS

 • Do not repair damaged batteries.

 Battery can be repaired only by

the manufacturer or in an authorised workshop.

 • When disposing of the worn out battery, take it to a service

point where you can utilize such dangerous wastes.

SAFETY REGULATIONS FOR THE CHARGER

 • Do not expose the charger to humidity or water.

 Ingress of

water into the charger increases risk of electric shock. Use the charger

only in dry rooms.

•

Disconnect the charger from power supply before starting any

maintenance or cleaning.

 • Do not use the charger when placed on flammable surface

(e.g. paper, textiles) or in proximity of flammable substance.

Greater charger temperature when charging increases risk of fire.

 • Check condition of the charger, cable and plug before each

use. Do not use the charger if any damage is found. Do not

try to disassemble the charger.

All repairs should be made at an

authorized service workshop. Improper charger assembly may cause

electric shock or fire.

•

Children or persons who are physically, emotionally or mentally

disabled and other persons, whose experience or knowledge

is insufficient to use the charger while following all safety rules

should not use the charger without supervision of person

responsible for their safety. Otherwise there is a risk of improper

use and injuries in consequence.

 • When the charger is not in use, it should be disconnected from

the mains network.

 • Observe all charging instructions. Do not charge the battery

in temperature outside of range defined in the rating data

table from the instruction manual.

Incorrect charging or

charging in temperature outside of defined range may damage the

battery and increase the risk of fire.

CHARGER REPAIRS

 • Do not repair damaged charger.

The charger can be repaired only

by the manufacturer or in an authorised workshop.

 • When disposing of the worn out charger, take it to a service

point where you can utilize such wastes.

CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and

additional safety systems are used, nevertheless there is always

a small risk of injuries at work.
Li-Ion batteries may leak, set on fire or explode when heated to

high temperature or short-circuited. Do not store the batteries

in a car in hot and sunny days. Do not open the battery. Li-Ion

batteries contain electronic protection devices that, if damaged,

may cause fire or explosion of the battery.

Explanation of used symbols

1

2

3

4

7

5

Max.

50°C

6

8

9

10

11

1.

Read instruction manual, observe warnings and safety

conditions therein.

2.

Use protective goggles and hearing protectors.

3.

Keep the tool away from children.

4.

Protect against rain.

5.

Use indoors, protect from water and moisture.

6.

Recycling.

7.

Protection class 2.

8.

Segregated waste collection.

9.

Do not throw cells into fire.

10.

Hazardous to water environment.

11.

Do not allow to heat above 50°C.

CONSTRUCTION AND USE

The impact driver is a battery-powered tool. Drive consists of a

brushless DC motor with planetary gear. The impact driver is used

for tightening and undoing screws and bolts in wood, metal or

plastics. High speed allows to use the device widely for self drilling

screws, and high torque allows to use the device for long screws in

wood. The device can be well used at heights and in hard to reach

areas. High torque mechanism creates the torque as short, high

peaks of circumferential impact, and tool reaction towards the

operator's hands during tightening is low.

Use the power tool in accordance with the manufacturer’s

instructions only.

DESCRIPTION OF DRAWING PAGES

Below enumeration refers to the device elements depicted on the

drawing pages of this manual.

1.

Tool holder

2.

Fixing sleeve of the tool chuck

3.

Casing

4.

Direction selector switch

5.

Handle

6.

Holder

7.

Illumination

8.

Gear switch button

9.

Gear display

10.

Switch

11.

Battery lock button

12.

Battery

13.

Charger

14.

LED diodes
