Button for battery level indication

16.

Battery level indicator (LED)

* Differences may appear between the product and drawing.

MEANING OF SYMBOLS

 WARNING

PREPARATION FOR OPERATION

REMOVING AND INSERTING THE BATTERY

•

Set the direction selector switch (4) in the middle position.

•

Press the battery lock button (11) and slide out the battery (12)

(fig. A).

•

Insert charged battery (12) into the handle holder, you should

hear when the battery lock button (11) snaps.

BATTERY CHARGING

The device is supplied with partially charged battery. Charge the

battery when ambient temperature is within range 4°C–40°C. New

battery, or one that has not been used for a long time, will reach full

efficiency after approximately 3 to 5 charge/discharge cycles.

•

Remove the battery (12) from the device (fig. A).

•

Connect the charger to mains socket (230 V AC.)

•

Slide the battery (12) into the charger (13) (fig. B). Make sure the

battery is properly fitted (pushed to the end).

When the charger is connected to a mains socket (230 V AC), the

green diode (14) on the charger turns on to indicate connected

supply.
When the battery (12) is placed in the charger (13), the red diode (14)

on the charger turns on to indicate that the charging is in progress.
At the same time green diodes (16) of the battery level indication are

flashing in different configurations, see description below.

•

All diodes are flashing – the battery is empty and requires

charging.

•

2 diodes are flashing – the battery is partially discharged.

•

1 diode is flashing – the battery level is high.

Once the battery has been charged, the diode (14) on the charger

lights green, and all battery level diodes (16) light continuously.

After some time (approx. 15 s) the battery level indication diodes

(16) turn off.

Do not charge the battery for more than 8 hours. Exceeding

this time limit may cause damage to battery cells. The charger

does not turn off automatically when the battery is full. Green

diode on the charger will remain on. Battery level indication

diodes turn off after some time. Disconnect power supply

before removing the battery from the charger socket. Avoid

consecutive short chargings. Do not charge the battery after

short use of the tool. Significant decrease of the period between

necessary chargings indicates that the battery is worn out and

should be replaced.

Batteries heat up when charging. Do not operate just after charging

– wait for the battery to cool down to room temperature. It will

prevent battery damage.

BATTERY LEVEL INDICATION

The battery is equipped with indication of the battery level (3

LED diodes) (16). To check battery level status, press the button

for battery level indication (15) (fig. C). When all diodes are lit, the

battery level is high. When 2 diodes are on, the battery is partially

discharged. When only one diode is lit, the battery is discharged and

must be recharged.
The power tool is equipped with electronic brake, which stops the

spindle immediately after the switch button (10) is released. The

brake allows for precise driving and prevents free spindle rotation

after switching off.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

Switching on – press the switch button (10).
Switching off – release the switch (10).
Each time the switch button (10) is pressed, the LED diode (7) turns

on to illuminate the workplace.

CHANGE OF GEAR

The impact driver features rotational speed adjustment, ranged at

three forward gears (clockwise) and two backward gears (counter-

clockwise). They can be changed with the gear switch button (8)

located in the bottom base of the impact driver.
When switching clockwise gears, one of three diodes (9) shows the

current operating gear. When you press the gear switch button (8

the device will switch to higher or lower gear (fig. D).
When changing the direction selector switch (4) to counter-

clockwise rotation, two modes are available. With the first, the

leftmost diode turns on and the impact driver starts with full speed

and slows down shortly after (for initial impact and undoing a bolt).
Pressing the gear selector switch (8) again turns off all diodes, speed

is maximal and constant, and still adjustable with the switch (10)

within the range of the selected gear.

CIRCUMFERENTIAL IMPACT ACTION

The tool rotates the spindle when tightening, and creates

circumferential impact. Impact action actuates automatically

when the load increases. Then a high peak torque is applied. Keep

watching the screw or bolt for full control over tightening. Keep

control over tightening force by adjusting rotational speed.

WORKING TOOL INSTALLATION

In order to change socket or bit, pull forward the sleeve that keeps

the tool holder (2).

•

Pull away the fixing sleeve of the tool holder (2) (fig. E) against the

spring force.

•

Insert working tool shank into the tool holder (1) and slide it in to

mechanical stop (it may be necessary to turn the working tool so

it can reach appropriate position) (fig. F).

•

Release the fixing sleeve of the tool holder (2), it will finally lock

the working tool. The tool holder fixing sleeve (2) will return to

its home position.

Deinstallation of the tool is similar to installation, only the sequence

of actions is reversed.

It is recommended to use driver bits designed for holders with

automated fixing system. Use additional driver bit adapter with

short driver bits.
RIGHT-LEFT DIRECTION OF ROTATION

Choose direction of spindle rotation with the direction selector

switch (4) (fig. G).
Clockwise rotation – move the switch (4) to the far left position.
Counter-clockwise rotation – move the switch (4) to the far right

position.

* In certain cases position of the switch related to rotation may be different than

specified. Please refer to graphic signs located on the switch or tool body.

Safe position of the direction selector switch (4) is in the middle, it

prevents accidental starting of the power tool.

•

When the switch is in this position, the power tool cannot be

started.

•

Use this position of the switch to change bits.

•

Make sure that the position of the direction selector switch (4) is

correct before starting the tool.

Do not change direction of rotation when the spindle of the

power tool is rotating.
