10

English

Variable Speed Trigger Switch (Fig. A)

To turn the tool on, squeeze the variable speed trigger
 switch

 3

. To turn the tool off, release the trigger switch. Your

Belt Hook and Magnetic Bit Holder (Fig. A)

Optional Accessories

WARNING: To reduce the risk of serious personal
injury, ONLY use the tool's belt hook to hang the
tool from a work belt. DO NOT

 use the belt hook for

tethering or securing the tool to a person or object during
use. DO NOT suspend tool overhead or suspend objects
from the belt hook.

WARNING: To reduce the risk of serious personal
injury,

ensure the screw holding the belt hook is secure.

CAUTION:

To reduce the risk of personal injury or

damage, DO NOT use the belt hook to hang the drill
while using as a spotlight.

iMPORTAnT:

When attaching or replacing the belt hook

 11

 or

magnetic bit holder

 13

, use only the mounting screw

 12

 that

is provided. Be sure to securely tighten the screw.
The belt hook and magnetic bit holder can be be attached
to either side of the tool using only the screw provided, to
accommodate left‑ or right‑ handed users. If the hook or
magnetic bit holder is not desired at all, it can be removed from
the tool.

Inserting and Removing the Battery Pack
from the Tool (Fig. B)

nOTE:

 Make sure your battery pack

 1

 is fully charged.

To Install the Battery Pack into the Tool Handle

1.  Align the battery pack

 1

 with the rails inside the tool’s

handle (Fig. B).

2.  Slide it into the handle until the battery pack is firmly seated

in the tool and ensure that you hear the lock snap into place.

To Remove the Battery Pack from the Tool

1.  Press the release button

 2

 and firmly pull the battery pack

out of the tool handle.

2.  Insert battery pack into the charger as described in the

charger section of this manual.

Fuel Gauge Battery Packs (Fig. B)

Some

D

e

WALT

 battery packs include a fuel gauge which

consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
To actuate the fuel gauge

 17

 , press and hold the fuel gauge

button. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to be recharged.

nOTE:

The fuel gauge is only an indication of the charge left on

the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑user application.

ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start‑up can cause injury.

WARNING:

 Use only

D

e

WALT

 battery packs and chargers.

Description (Fig. A)

WARNING:

Never modify the power tool or any part of it.

Damage or personal injury could result.

Components

1

Battery pack

2

Battery release button

3

Variable speed trigger switch

4

Forward/reverse control button

5

Torque adjustment collar

6

Keyless chuck

7

Chuck sleeve

8

Speed selector

9

Worklight

10

Worklight switch

11

Belt hook (Optional accessory)

12

Mounting screw

13

Bit holder (Optional accessory)

14

Side handle

15

Main handle

Intended Use

These hammerdrills are designed for professional drilling,
percussion drilling and screwdriving applications.

DO nOT

 use under wet conditions or in the presence of

flammable liquids or gases.
These drills/drivers/hammerdrills are professional power tools.

DO nOT

 let children come into contact with the tool.

Supervision is required when inexperienced operators use
this tool.
•

Young children and the infirm.

This appliance is not

intended for use by young children or infirm persons
without supervision.

•  This product is not intended for use by persons (including

children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.

Date Code Position (Fig. B)

The date code

 16

, which also includes

the year of manufacture,

is printed into the housing.
Example:

2020 XX XX

Year and week of Manufacture

n

Visible radiation. Do not stare into light.
