9

English

Markings on Tool

The following pictograms are shown on the tool:

a

Read instruction manual before use.

Package Contents

The package contains:
1  Brushless cordless hammerdrill
1 Kitbox
1 Charger
1  Side handle
1  Magnetic bit holder (Optional accessory)
1  Belt hook (Optional accessory)
1   Li‑Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1, Y1 models)
2   Li‑Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2, Y2 models)
3   Li‑Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3, Y3 models)
1   Instruction  manual

nOTE:

 Battery packs, chargers and kitboxes are not included

with N models. Battery packs and chargers are not included with
NT models. B models include Bluetooth® battery packs.

nOTE:

 The Bluetooth® word mark and logos are registered

trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by

D

e

WALT

 is under license. Other trademarks and

trade names are those of their respective owners.

•  Check for damage to the tool, parts or accessories which may

have occurred during transport.

•  Take the time to thoroughly read and understand this manual

prior to operation.

Battery Type

The following tools  operate on a 18 volt battery pack: DCD999
These battery packs may be used:  DCB181, DCB182, DCB183,
DCB183B, DCB183G, DCB184, DCB184B, DCB184G, DCB185,
DCB187, DCB189, DCB546, DCB547, DCB548. Refer to

Technical

Data

 for more information.

u

Charge only between 4 ˚C and 40 ˚C.

v

Only for indoor use.

x

Discard the battery pack with due care for
the environment.

y

Charge

D

e

WALT

 battery packs only with designated

D

e

WALT

 chargers. Charging battery packs other than

the designated

D

e

WALT

 batteries with a

D

e

WALT

charger may make them burst or lead to other
dangerous situations.

z

Do not incinerate the battery pack.

B

USE (without transport cap). Example: Wh rating
indicates 108 Wh (1 battery with 108 Wh).

A

TRANSPORT (with built‑in transport cap). Example: Wh
rating indicates 3 x 36 Wh (3 batteries of 36 Wh).

Use Mode:

When the FLEXVOLT

TM

 battery stands alone or is in

a

D

e

WALT

 18V product, it will operate as an 18V battery. When

the FLEXVOLT

TM

 battery is in a 54V or a 108V (two 54V batteries)

product, it will operate as a 54V battery.

Transport Mode:

When the cap is attached to the FLEXVOLT

TM

battery, the battery is in Transport mode. Keep the cap
for shipping.
When in Transport mode, strings
of cells are electrically
disconnected within the pack
resulting in 3 batteries with a
lower Watt hour (Wh) rating as compared to 1 battery with a
higher Watt hour rating. This increased quantity of 3 batteries
with the lower Watt hour rating can exempt the pack from
certain shipping regulations that are imposed upon the higher
Watt hour batteries.
For example, the Transport
Wh rating might indicate
3 x 36 Wh, meaning
3 batteries of 36 Wh each.
The Use Wh rating might
indicate 108 Wh (1 battery implied).

Storage Recommendations

1.  The best storage place is one that is cool and dry away

from direct sunlight and excess heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not in use.

2.  For long storage, it is recommended to store a fully charged

battery pack in a cool, dry place out of the charger for
optimal results.

nOTE:

 Battery packs should not be stored completely

depleted of charge. The battery pack will need to be recharged
before use.

Labels on Charger and Battery Pack

In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
following pictographs:

L

Read instruction manual before use.

p

See

Technical Data

 for charging time.

q

Do not probe with conductive objects.

r

Do not charge damaged battery packs.

s

Do not expose to water.

t

Have defective cords replaced immediately

Example of Use and Transport Label Marking
