Gear Selection, Mechanical

f

The gear selector 3 can be actuated at
standstill or when the machine is running.
However, this should not be done while op-
erating at full load or maximum speed.

Two speed ranges can be preselected with the
gear selector

3

.

Gear I:

Low speed range; for screwdriving or working
with large drilling diameter.

Gear II:

High speed range; for working with small drilling
diameter.
If the gear selector

3

 cannot be pushed through

to the stop, lightly turn the drill chuck with drill.

Setting the Operating Mode

Drilling and Screwdriving

Set the preselection ring

2

 to the

“Drilling without impact” symbol.

Impact Drilling (GSB 36 V-LI)

Set the preselection ring

2

 to the “Im-

pact drilling” symbol.

Switching On and Off

To

start

 the machine, press the On/Off switch

6

and keep it depressed.
To switch off the machine,

release

 the On/Off

switch

6

.

Adjusting the Speed

The speed of the switched on power tool can be
variably adjusted, depending on how far the
On/Off switch

6

 is pressed.

Light pressure on the On/Off switch

6

 results in

a low rotational speed. Further pressure on the
switch results in an increase in speed.

Fully automatic spindle locking (Auto-lock)

When the On/Off switch

6

 is not pressed, the

drill spindle and thus the tool holder are locked.
This enables screws to be screwed in, even
when the battery is empty and allows for the
machine to be used as a screwdriver.

Run-on Brake

When the On/Off switch

6

 is released, the chuck

brakes to a stop, thus preventing the run-on of
the tool.
When driving in screws, wait until the screw is
screwed in flush with the material and then re-
lease the On/Off switch

6

. By doing so, the head

of the screw does not penetrate into the materi-
al.

Temperature Control Indicator

The red LED of the temperature control indica-
tor

10

 signals that the battery or the electronics

of the power tool (when the battery is inserted)
are not within the optimum temperature range.
In this case, the power tool will not operate at
full capacity.
Temperature control of the battery:

–

The red LED

10

 lights up continuously after

inserting the battery into the charger: The
battery is not within the charging tempera-
ture range between 0 ° C and 45 ° C and can-
not be charged.

–

The red LED

10

 flashes when pushing button

12

 or pressing the On/Off switch

6

 (when the

battery is inserted): The battery is not wihin
the temperature range for operation of

– 10 ° C to + 60 ° C.

–

The battery switches off at a temperature
above 70 ° C until the optimum temperature
range is reached again.

Temperature control of the power tool electron-
ics:

–

The red LED

10

 lights up continuously when

pressing the On/Off switch

6

: The tempera-

ture of the power tool electronics is above
75 ° C.

–

At a temperature above 90 ° C , the electron-
ics of the power tool switch off until the tem-
perature is within the allowable temperature
range again.
