2
CAPABILITIES
ENGLISH
Model 75Cs
KEY
A. SafeSense
®
Technology
B. Paper entry
C. See safety instructions
D. Card/CD entry
E. Window
F. Pull-out bin
G. Disconnect power switch
1. OFF
2. ON
H. SafeSense
®
override switch
I. Control switch and Indicator lights
I 1. Auto-On (green)
O 2. OFF
R 3. Reverse
4. Overheat (red)
5. Bin Open (red)
6. Remove Paper (red)
7. SafeSense
®
(yellow)
G.
E.
B.
A.
C.
D.
F.
I.
H.
Active
Not active
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
15
2
Set to Auto-On (I)
PAPER OR CD/CARD
BASIC SHREDDING OPERATION
1
Plug in and put
disconnect power
switch in ON (I) position
Continuous operation:
Up to 12 minute maximum
NOTE:
Shredder runs briefly
after each pass to clear entry.
Continuous operation beyond
12-minutes will trigger
20-minute cool down period.
15
• Operation, maintenance, and service requirements are covered in the instruction
manual. Read the entire instruction manual before operating shredders.
• Keep away from children and pets. Keep hands away from paper entry. Always
set to off or unplug when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair, etc. – away from shredder
openings. If object enters top opening, switch to Reverse (R) to back out object.
• Never use aerosol products, petroleum based lubricants or other flammable
products on or near shredder. Do not use canned air on shredder.
• Do not use if damaged or defective. Do not disassemble shredder.
Do not place near or over heat source or water.
• This shredder has a Disconnect Power Switch (G) that must be in the ON (I)
position to operate shredder. In case of emergency, move switch to OFF (O)
position. This action will stop shredder immediately.
• Avoid touching exposed cutting blades under shredder head.
• Shredder must be plugged into a properly grounded wall outlet or socket of the
voltage and amperage designated on the label. The grounded outlet or socket
must be installed near the equipment and easily accessible. Energy converters,
transformers, or extension cords should not be used with this product.
• FIRE HAZARD – Do NOT shred greeting cards with sound chips or batteries.
• For indoor use only.
• Unplug shredder before cleaning or servicing.
15
15
12
12
PS-77C
s
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
PS-77C
s
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
Feed paper straight into
paper entry and release
or
3
Feed into card/CD
entry and release
When finished
shredding set to
OFF (O)
5
4
Will shred:
Paper, credit cards, CD/DVD, staples, small paper clips and junk mail
Will not shred:
Continuous forms, adhesive labels, transparencies, newspaper, cardboard,
large paper clips, laminates or plastic other than noted above
Paper shred size:
Cross-Cut ......................................................................................................4mm x 38mm
Maximum:
Sheets per pass ........................................................................................................... 12*
Cards/CDs per pass ....................................................................................................... 1*
Paper entry width .................................................................................................. 230mm
* A4 (70g), paper at 220-240V/50/60 Hz, 1.5Amps; heavier paper, humidity or other than
rated voltage may reduce capacity. Maximum recommended daily usage rates: 500 sheets
per day; 25 cards; 10 CDs.
12 sheets per pass.
3
12
12
PS-77C
s
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
PRODUCT MAINTENANCE
Gently pull uncut
paper from paper
entry. Plug in
12
12
12
12
2
1
3
Press and hold
Reverse (R) for 2-3
seconds
PAPER JAM
Alternate slowly back and forth
Set to Auto-On (I) and
resume shredding
Set to Off (O)
and unplug
ADvANCED PRODUCT FEATURES
SET-UP AND TESTING
1
Turn the shredder ON
(I) to activate
SafeSense
®
Touch test area and
look for the SafeSense
®
indicator to illuminate
2
SafeSense
®
is active
and working properly
12
12
3
TROUBLESHOOTING
Overheat Indicator: When the Overheat Indicator is illuminated, the shredder has exceeded its maximum operating temperature and needs to cool down. This
indicator will remain illuminated and the shredder will not operate for the duration of the recovery time. See Basic Shredding Operation for more information about
the continuous operation and recovery time for this shredder.
Bin Open: The shredder will not run if the bin is open. When illuminated, close the bin to resume shredding.
Remove Paper: When illuminated, press reverse (R) and remove paper. Reduce paper quantity to an acceptable amount and refeed into paper entry.
SafeSense
®
Indicator: If hands are too close to the paper entry, the SafeSense
®
indicator will illuminate and the shredder will stop shredding.
SafeSense
®
Technology
Stops shredding immediately
when hands touch the paper
opening.
All cross-cut shredders require oil for peak performance. If not oiled, a
machine may experience diminished sheet capacity, intrusive noise when
shredding and could ultimately stop running. To avoid these problems, we
recommend you oil your shredder each time you empty your waste bin.
OILING SHREDDER
FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE
*Apply oil across entry
Set to Off (O)
Press and hold Reverse
(R) 2-3 seconds
CLEANING AUTO-START INFRARED SENSORS
Paper detection sensors are designed for maintenance free operation. However, on rare occasions, the
sensors may become blocked by paper dust causing the motor to run even if there is no paper present.
(Note: two paper detection sensors are located in the center of the paper entry)
.
15
15
* Only use a non-aerosol vegetable oil in long nozzle container such as Fellowes 35250
TO CLEAN THE SENSORS
Locate Auto-start
infrared sensor
Using cotton swab, wipe
away any contamination
from the paper sensors
Dip cotton swab in
rubbing alcohol
2
12
12
12
4
3
Set to Off (O)
and unplug
1
LIMITED PRODUCT WARRANTY
Limited Warranty: Fellowes, Inc. (“Fellowes”) warrants the parts of the machine to be free of
defects in material and workmanship and provides service and support for 2 years from the date of
purchase by the original consumer. Fellowes warrants the cutting blades of the machine to be free
from defects in material and workmanship for 5 years from the date of purchase by the original
consumer. If any part is found to be defective during the warranty period, your sole and exclusive
remedy will be repair or replacement, at Fellowes’ option and expense, of the defective part. This
warranty does not apply in cases of abuse, mishandling, failure to comply with product usage
standards, shredder operation using an improper power supply (other than listed on the label), or
unauthorized repair. Fellowes reserves the right to charge the consumers for any additional costs
incurred by Fellowes to provide parts or services outside of the country where the shredder is initially
sold by an authorized reseller. ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE APPROPRIATE
WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any consequential
or incidental damages attributable to this product. This warranty gives you specific legal rights.
The duration, terms, and conditions of this warranty are valid worldwide, except where different
limitations, restrictions, or conditions may be required by local law. For more details or to obtain
service under this warranty, please contact us or your dealer.
For more information about all of Fellowes Advanced Product Features go to
www.fellowes.com
1
2
3
4
12
12
5
6
