12

• Grinding wheels can only be used according to its purpose.

• The side surface of the grinding wheel should not be used for

cutting.

Cut-off grinding wheels are designed for removal of material

with the disc edge. The influence of lateral forces on the grinding
wheels may break them.

• Undamaged fastening flanges of a correct size and shape

should always be used for a selected grinding wheel.

Proper

flanges support the grinding wheel and reduce the risk of its breaking.
Flanges for cut-off wheels may differ from flanges designed for other
grinding wheels.

• Do not use worn grinding wheels from larger power tools.

Grinding wheels for larger power tools are not designed for higher
rotational speed, which is specific to smaller power tools. Thus, such
grinding wheels may break.

Additional specific safety guidelines for cutting with a cut-off
wheel

• Always prevent a cut-off wheel from seizure and avoid excessive

pressure. Do not make too deep cuts.

The overload of a cut-off

wheel increases its load and tendency for seizure or locking, and thus
may result in recoil or breaking of a cut-off wheel.

• Avoid areas in front of and behind a rotating cut-off wheel.

When a cut-off wheel is moved onto a workpiece away from the
operator, it may cause the power tool to kick back as a result of recoil,
with a rotating cut-off wheel pointing directly towards the operator.

• When a cut-off wheel seizes or you take a break from work,

switch off the power tool and wait until it comes to a complete
stop. Do not attempt to remove a rotating cut-off wheel from a
cutting place, since it may cause recoil.

Find and eliminate a cause

of seizure.

• Do not switch the power tool back on, if it is still sunk in a

workpiece. Before you continue to cut, a cut-off wheel must
reach its full rotational speed.

Otherwise, a cut-off wheel may

catch, spring back from a workpiece and cause recoil.

• Boards and large objects should be supported to reduce the

risk of recoil caused by a seized cut-off wheel.

 Large objects may

bend under their own weight. A workpiece should be supported from
both sides, both near the cut line and its edge.

• Special caution should be exercised, when holes are cut in a

wall or in confined spaces.

 As a cut-off wheel sinks into a workpiece,

it may cause the power tool to recoil, when it encounters a gas or water
supply line, power conductors or other objects.

Specific safety guidelines for sanding with sandpaper

• Do not use too large sheets of sandpaper.  Always follow

guidelines of a manufacturer, when the size of a sandpaper is
selected.

 Sandpaper protruding beyond a grinding disc may cause

injuries and result in locking and tearing of sandpaper, or recoil.

Specific safety guidelines for working with wire brushes

• It should always be remembered that pieces of wire are lost

even during normal use. Do not overload wires by putting
excessive pressure.

Airborne pieces of wire may easily puncture thin

clothing and/or skin.

• If a guard is recommended to be used, prevent a brush from

touching the guard.

A brush diameter for plates and pots may

increase due to the pressure and centrifugal forces.

Additional safety guidelines

• Before connecting to the power source, always make sure the

supply voltage is compatible with the value specified on the
nameplate of the tool.

• Before the grinder is connected, always check the power cord.

In case of damage, have it repaired in an authorised workshop.

• Before all installation works, the plug should be taken out of

the receptacle.

• Grinding tools should be checked before each use. A grinding

tool must be correctly fastened and should rotate freely. As
part of the test, the tool should be switched on with no load
for at least one minute in a safe position. Do not use damaged
or vibrating grinding tools. Grinding tools should be round.
Damaged grinding tools may break and cause injuries.

• Once a grinding tool is installed and before the grinder is

switched on, check the grinding tool for correct installation and
free rotations, and whether it does not catch the guard.

• The spindle lock button can be activated, only when the grinder

spindle does not move.

• In case of tools adapted for fastening of grinding wheels with a

threaded opening, make sure the grinding wheel thread length
is suitable for the spindle thread length.

• Always secure the workpiece. It is always preferable to secure

the workpiece in a vice or other fastening tool than holding it
in your hand.

• If own weight of the workpiece does not guarantee a stable

position, it should be fastened.

• Do not touch cut-off and grinding wheels, before they cool

down.

• Do not exert lateral pressure on the grinding or cut-off wheel.

• Do not cut a workpiece of a thickness larger than the maximum

cutting depth of the cut-off wheel.

NOTE: The tools is intended for indoor works.

Despite using the construction, which is safe by design itself,
protection means and additional safety features, there is always a
residual risk of injuries during operation.

Descriptions of used pictograms.

1

2

3 4 5 6

7 8

1

.

Warning, take special precautions.

2

.

Read the instruction manual, observe warnings and safety
conditions included in it!

3.

Use personal protection equipment (safety goggles, ear
protectors).

4.

Use safety gloves.

5.

Disconnect the power cord, before maintenance or repair works
are begun.

6.

Keep out of reach of children.

7.

Protect against rain

8.

Protection class II

DESIGN AND APPLICATION

The angle grinder is a hand-held power tool with the II class isolation.
The power tool is driven with a single-phase, commutator motor,
whose rotational speed is reduced by means of an intersecting axis
gear. The power tool can used both for grinding and cutting. This type
of power tools is widely used for removal of burrs from metal surfaces,
weld surface processing, cutting light-wall tubes and other small
metal objects etc. They are used in engineering industry, automotive
and chemical industry. With the use of proper tools, the angle grinder
can be used not only for cutting or grinding, but also for rust and paint
coats removal.
The areas of its application include repair and construction works, not
only related to metals. The angle grinder can also be used for cutting
and grinding of construction materials, such as brick, paving stones,
ceramic tiles, etc.

The power tool is designed for dry operation only and it must not
be used for polishing. The power tool should be used according
to its purpose.

Use inconsistent with its purpose

• Do not work materials that contain asbestos.

Asbestos is

carcinogenic.

• Do not work materials, whose dust is inflammable or explosive.

During operation, the power tool produces sparks, which may ignite
emitted vapours.

• Do not use cut-off wheels for grinding.

The cut-off wheels are used

to cut with its face, while grinding with lateral surface of such a cut-off
wheel threatens with its damages and puts the operate in danger of
injuries.

DESCRIPTION OF GRAPHIC PAGES

The below list refers to device components shown in the graphic
pages of this instruction manual.
