EN

EN

1. Turn On/Off

3. Cleaning Mode

How to Use

Press and hold the button

 for 3 seconds to turn on the robot. Once the

power indicator turns solid white, the robot is on standby. To turn off the

robot, press and hold the button   for 3 seconds when the robot is not

moving.

Dreame Bot Z10 Pro has four cleaning modes: Quiet, Standard, Strong, and

Turbo. The default mode is Standard. You can specify the cleaning mode in

the Mi Home/Xiaomi Home app.

2. Start Cleaning

Press the button

  briefly to turn on the robot. Upon activation, the robot

will accurately map out a route, methodically clean along the edges and

walls, then finish by cleaning each room in an S-shaped pattern to ensure

a thorough job.

5. Spot Clean Mode

When the robot is paused or in Standby Mode, press and hold the button    for

3 seconds to start Spot Clean Mode. In this mode, it will clean a square-shaped

area of 1.5×1.5 meters directly around the robot. When the spot cleaning is

done, the robot will automatically return to its original location and power off.

Note:

Activating Spot Clean Mode will end the current cleaning task of the robot.

6. Additional App Functions

You can enable more functions via Mi Home/Xiaomi Home app such as

selected room cleaning, zone cleaning, forbidden area/virtual no-go

zones, etc.

Note:

• Follow the instructions on the app interface to use more functions.

• The version of the app might have been updated; please follow the instructions

   based in the current app version.

4. Pause/Sleep Mode

Pause:

Press any button briefly to pause the robot during cleaning.

Sleep Mode:

The robot will automatically enter Sleep Mode after 10

minutes of inactivity, then the power indicator and charging indicator will

go off. To wake up the robot, press any button.

Note:

• The robot will turn off automatically if left in Sleep Mode for more than 12 hours.
• When the robot is paused, placing it onto the base will end the current cleaning

  task.

7. Use the Mopping Function

How to Use

It is recommended that all floors are vacuumed at least three times before

the first mopping session to achieve a better cleaning effect.

1) Dampen the mop pad and wring out excess water. Insert the mop pad into

the slot of the water tank as shown in the figure, and paste the pad firmly.

3) Align the mopping module as indicated by the arrow, then slide it into the

back of the robot until it clicks into place. Press the button

 or use the Mi

Home/Xiaomi Home app to start cleaning.

2) Open the water tank lid, fill the tank with water, then securely close the lid.

4) Press the two side clips inwards and slide the water tank backwards to

separate it from the robot.

Note:

• It is not recommended to use the mopping function on carpets.
• Use the app to adjust the water flow as required.

Note:

 Do not use detergent or disinfectant.

Note:

When the robot is charging or not in use, remove the mopping module,

pour out all the remaining water in the tank, and clean the mop pad to prevent

mildew or odors.

Click

Click

①

②

③
