The  following  table  lists  possible  causes  and  solutions  in  terms  of  different  light  status.  For  more  support,

please refer to the section "FAQ" in this manual.

Status Indicator

Light Status

Possible Cause

Solution

Off

No power supply

Check and ensure that the power supply for the base is normal.

The robot in the DND period

The robot with full charge in sleep mode

/

White

The robot not on the base

/

Breathing White

The robot is charging

/

Blinking Orange

Error

Check whether a dust collection bag is installed. If not, install one.
Check whether the dust collection bag is installed in place.

Check whether the upper cover is closed. If not, close the upper cover tightly.

Check whether the bag is full. If so, replace it.
Remove debris around the dust intake of the robot and base.

Unplug the power cord of base, and check whether there are any foreign objects

that block the air duct cover. If any, clean them.

Check whether the dust bin of robot is installed.
For other errors, contact qualified technicians or after-sales service.

FAQ

Problem Type

Solution

Robot does not turn on

The battery level is low. Recharge the robot on the base, then try it again.
The ambient temperature is too low (below 0° C) or too high (above 40° C). The operating temperature of the robot is

0° C to 40° C.

Robot cannot recharge

The base is not receiving power. Please confirm that both ends of the power cord are plugged in correctly.
Poor contact. Clean charging contacts of the base and robot.

Robot cannot return to the base

There are too many obstructions around the base. Place the base in a more open area.
Please clean the signaling area of the base.
Moving the robot may cause it to re-position itself or re-map its surroundings. If the robot is too far from the base, it

might not be able to automatically return on its own, in which case you need to manually place the robot onto the base.

Robot is malfunctioning

Turn off the robot and then reactivate it.

Robot is making a strange noise

A foreign object may be caught in the main brush, side brush, or one of the main wheels. Stop the robot and remove

any debris.

Robot no longer cleans effi

-

ciently or leaves dust behind

The dust bin is full. Please clean the dust bin and dust intake.
The filter is blocked. Please clean it.
A foreign object is caught in the main brush. Please clean it.
