EN
25
s
Fig. 6-4
5) If hair found on the floor brush, press the roll brush release tab (7) as shown below
to open the roll brush cover, and then remove the roll brush (8).
Fig. 6-5a Fig. 6-5b
6) To remove hair from the brush, run the blade of the scissors along the groove to cut
the hair, pull it out, and then reinsert it into the floor brush.
Fig. 6-7a
NOTE: It is recommended to clean the duct cup after every use. If the filter holder and
HEPA filter are blocked caused by the cumulation of dust, please clean or replace it in
time. The electric roll brush may be wrapped with some hair or other dirt after long
time use, so please clean it in time to make the appliance work efficiently.
7
8
s
then empty the dust cup and rinse it with water. Then it is necessary to wipe and dry
completely.
Fig. 6-2a Fig. 6-2b
3) Grasp the filter handle (3) and turn it counterclockwise to separate the filter holder
(6) from the HEPA filter (5).
Clean the HEPA filter. The HEPA filter must not be washed!
The filter holder can be washed under the tap, then dried completely and dried.
Fig. 6-3a Fig. 6-3b
4) After cleaning the dust cup assembly, please install the HEPA filter into the filter
holder firstly and then put them into the dust cup, after it, install the dust cup into the
sub-unit.
3
4
5
6
s
then empty the dust cup and rinse it with water. Then it is necessary to wipe and dry
completely.
Fig. 6-2a Fig. 6-2b
3) Grasp the filter handle (3) and turn it counterclockwise to separate the filter holder
(6) from the HEPA filter (5).
Clean the HEPA filter. The HEPA filter must not be washed!
The filter holder can be washed under the tap, then dried completely and dried.
Fig. 6-3a Fig. 6-3b
4) After cleaning the dust cup assembly, please install the HEPA filter into the filter
holder firstly and then put them into the dust cup, after it, install the dust cup into the
sub-unit.
3
4
5
6
s
then empty the dust cup and rinse it with water. Then it is necessary to wipe and dry
completely.
Fig. 6-2a Fig. 6-2b
3) Grasp the filter handle (3) and turn it counterclockwise to separate the filter holder
(6) from the HEPA filter (5).
Clean the HEPA filter. The HEPA filter must not be washed!
The filter holder can be washed under the tap, then dried completely and dried.
Fig. 6-3a Fig. 6-3b
4) After cleaning the dust cup assembly, please install the HEPA filter into the filter
holder firstly and then put them into the dust cup, after it, install the dust cup into the
sub-unit.
3
4
5
6
Fig. 13
Fig. 15
Fig. 14
4. After cleaning the dust cup assembly, please install the
HEPA filter into the filter holder firstly and then put them
into the dust cup, after it, install the dust cup into the
sub-unit (see Fig. 15).
5. If hair found on the floor brush, press the roll brush
release tab (7) as shown below to open the roll brush
cover, and then remove the roll brush (8) (see Fig. 16-17).
s
Fig. 6-4
5) If hair found on the floor brush, press the roll brush release tab (7) as shown below
to open the roll brush cover, and then remove the roll brush (8).
Fig. 6-5a Fig. 6-5b
6) To remove hair from the brush, run the blade of the scissors along the groove to cut
the hair, pull it out, and then reinsert it into the floor brush.
Fig. 6-7a
NOTE: It is recommended to clean the duct cup after every use. If the filter holder and
HEPA filter are blocked caused by the cumulation of dust, please clean or replace it in
time. The electric roll brush may be wrapped with some hair or other dirt after long
time use, so please clean it in time to make the appliance work efficiently.
7
8
Fig. 16
Fig. 17
