EN

21

OPERATION INSTRUCTION

Operate the whole unit

There are two switches including power switch (1) and power

regulation button (2) (see Fig. 5). Press down power switch (1), the

motor starts to run, the floor brush indicator turns on and the appliance

enters into working condition; Press down the power regulation button

(2), the cleaner will change to the Turbo Mode in which it achieves a

much better cleaning performance on a hard-to-clean surface. Once

the power regulation button is press again, the cleaner will change

back to the Normal Mode in which the cleaner will have a longer

running time. Press the power switch (1) if you want to make the

appliance stop working. During operation, please pay attention to

charge quantity indicators (3), the indicators will extinguish gradually

as the charge quantity reduces and the appliance will stop working

automatically when all the indicators extinguish.

Turbo brush is equipped with a safety which will ensure that it shuts

itself off if, for example, objects which are too large are sucked up, or

if fingers become tangled in the floor brush. This is for personal safety

and to protect the motor. To restart the floor brush, press 2 times the

on/off button or the power regulation button.

s

Fig.

４

-

１

Turbo brush is equipped with a safety which will ensure that it shuts itself off if, for

example, objects which are too large are sucked up, or if fingers become tangled in the

floor brush. This is for personal safety and to protect the motor. To restart the floor

brush, press 2 times the on/off button or the speed control.

4.2 Operate the sub-unit (detachable handheld vacuum cleaner)

  Press down the sub-unit release button (4) (see Fig.4.2), grasp the handle of
sub-unit to remove it by following the arrow shown, and then press down the sub-unit
switch (5) (see Fig.4-3), the sub-unit enters into working condition, and you can press
the switch (5) to make it stop working.

If need to use brush for upholstered furniture, please insert it into the suction nozzle of
sub-unit by following Fig. 4-3, and then activate it again; If need to use crevice nozzle,
insert it into the suction nozzle of sub-unit by following Fig. 4-4, and then activate it
again.




2

1

3

Fig. 5
