EN

22

Operate the sub-unit (detachable handheld vacuum cleaner)

Press down the sub-unit release button (4) (see Fig. 6), grasp the

handle of sub-unit to remove it by following the arrow shown, and

then press down the sub-unit switch (5) (see Fig. 7), the sub-unit

enters into working condition, and you can press the switch (5) to

make it stop working.

If need to use brush for upholstered furniture, please insert it into

the suction nozzle of sub-unit by following Fig. 7, and then activate it

again; If need to use crevice nozzle, insert it into the suction nozzle of

sub-unit by following Fig. 7, and then activate it again.

s




Fig. 4-2                 Fig.4-3                           Fig. 4-4

5. CHARGING INSTRUCTION

5.1 Fix the charger by following Fig.3.3, insert the small end of adaptor into the
charger stand by following Fig. 5-1a.

5.2 Insert the large end of adaptor into power outlet and then connect the power source
well

（

see Fig. 5-1b

）

            Fig. 5-1a                                   Fig. 5-1b


5.3 Lift the appliance and put it onto the charger, make the socket of body (1) cover
the charger stand (2) (Fig.5-2a), at that time, the electricity quantity indicator turns on,

4

5

Fig. 6

Fig. 7
