OPERATION

CAUTION:

Always use the side grip (auxiliary

handle) and firmly hold the tool by both side grip

and switch handle during operations.

CAUTION:

Always make sure that the work-

piece is secured before operation.

►

Fig.12

Hammer drilling operation

CAUTION:

 There is tremendous and sudden

twisting force exerted on the tool/drill bit at the time of

hole break-through, when the hole becomes clogged

with chips and particles, or when striking reinforcing

rods embedded in the concrete.

Always use the side

grip (auxiliary handle) and firmly hold the tool by

both side grip and switch handle during opera-

tions.

 Failure to do so may result in the loss of control

of the tool and potentially severe injury.

Set the action mode changing knob to the

 symbol.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.
Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the drill bit partially from the hole.

By repeating this several times, the hole will be cleaned

out and normal drilling may be resumed.

NOTE:

 Eccentricity in the drill bit rotation may occur

while operating the tool with no load. The tool auto-

matically centers itself during operation. This does not

affect the drilling precision.

Chipping/Scaling/Demolition

Set the action mode changing knob to the  symbol.

Hold the tool firmly with both hands. Turn the tool on

and apply slight pressure on the tool so that the tool will

not bounce around, uncontrolled.

Pressing very hard on the tool will not increase the

efficiency.

►

Fig.13

Drilling in wood or metal

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

NOTICE:

Never use “rotation with hammering”

when the drill chuck is installed on the tool.

 The

drill chuck may be damaged.

Also, the drill chuck will come off when reversing the

tool.

NOTICE:

Pressing excessively on the tool will

not speed up the drilling.

 In fact, this excessive

pressure will only serve to damage the tip of your drill

bit, decrease the tool performance and shorten the

service life of the tool.

Set the action mode changing knob to the   symbol.

You can drill up to 13 mm (1/2″) diameter in metal and

up to 32 mm (1-1/4″) diameter in wood.

Use a drill chuck assembly (optional accessory). When

installing it, refer to the section “Installing or removing

drill bit/chisel”.

►

Fig.14:

1.

 Drill chuck assembly (optional accessory)

To install the drill bit, place it in the chuck as far as it will

go. Tighten the chuck by hand. Place the chuck key in

each of the three holes and tighten clockwise. Be sure

to tighten all three chuck holes evenly.

To remove the drill bit, turn the chuck key counterclock-

wise in just one hole, then loosen the chuck by hand.

►

Fig.15:

1.

 Chuck key

Diamond core drilling

NOTICE:

If performing diamond core drilling

operations using “rotation with hammering”

action, the diamond core bit may be damaged.

When performing diamond core drilling operations,
always set the change lever to the   position to use

"rotation only" action.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and unplugged before attempting to

perform inspection or maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY, repairs,

carbon brush inspection and replacement, any other

maintenance or adjustment should be performed by

Makita Authorized or Factory Service Centers, always

using Makita replacement parts.
