4 ENGLISH

ENGLISH (Original instructions)

SPECIFICATIONS

Model:

M8701

Drilling capacities

Concrete

26 mm

Core bit

68 mm

Diamond core bit (dry type)

80 mm

Steel

13 mm

Wood

32 mm

No load speed

0 - 1,200 min

-1

Blows per minute

0 - 4,500 min

-1

Overall length

362 mm

Net weight

2.7 kg

Safety class

/II

•

Due to our continuing program of research and development, the specifications herein are subject to change without notice.

•

Specifications may differ from country to country.

•

Weight according to EPTA-Procedure 01/2003

Symbols

The followings show the symbols used for the equip-

ment. Be sure that you understand their meaning before

use.

Read instruction manual.

DOUBLE INSULATION

Only for EU countries

Do not dispose of electric equipment

together with household waste material! In

observance of the European Directive, on

Waste Electric and Electronic Equipment

and its implementation in accordance with

national law, electric equipment that have

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

The tool is intended for hammer drilling and drilling in

brick, concrete and stone as well as for chiselling work.

It is also suitable for drilling without impact in wood,

metal, ceramic and plastic.

Power supply

The tool should be connected only to a power supply of

the same voltage as indicated on the nameplate, and

can only be operated on single-phase AC supply. They

are double-insulated and can, therefore, also be used

from sockets without earth wire.

Noise

The typical A-weighted noise level determined accord-

ing to EN60745:

Sound pressure level (L

pA

) : 90 dB(A)

Sound power level (L

WA

) : 101 dB (A)

Uncertainty (K) : 3 dB(A)

WARNING:

Wear ear protection.

Vibration

The vibration total value (tri-axial vector sum) deter-

mined according to EN60745:

Work mode: hammer drilling into concrete

Vibration emission (a

h, HD

): 16.5 m/s

2

Uncertainty (K) : 1.5 m/s

2

Work mode: chiselling function with side grip

Vibration emission (a

h, Cheq

): 9.0 m/s

2

Uncertainty (K) : 1.5 m/s

2

Work mode: drilling into metal

Vibration emission (a

h,D

) : 2.5 m/s

2

 or less

Uncertainty (K) : 1.5 m/s

2

NOTE:

 The declared vibration total value(s) has been

measured in accordance with a standard test method

and may be used for comparing one tool with another.

NOTE:

 The declared vibration total value(s) may also

be used in a preliminary assessment of exposure.

WARNING:

The vibration emission during actual

use of the power tool can differ from the declared val-

ue(s) depending on the ways in which the tool is used

especially what kind of workpiece is processed.

WARNING:

Be sure to identify safety measures

to protect the operator that are based on an estima-

tion of exposure in the actual conditions of use (tak-

ing account of all parts of the operating cycle such

as the times when the tool is switched off and when

it is running idle in addition to the trigger time).
