7 ENGLISH

Selecting the action mode

NOTICE:

Do not rotate the action mode chang-

ing knob when the tool is running.

 The tool will be

damaged.

NOTICE:

To avoid rapid wear on the mode

change mechanism, be sure that the action mode

changing knob is always positively located in one

of the three action mode positions.

Rotation with hammering

For drilling in concrete, masonry, etc., rotate the action
mode changing knob to the

 symbol. Use a tungsten-

carbide tipped bit (optional accessory).

►

Fig.3:

1.

 Action mode changing knob

Rotation only

For drilling in wood, metal or plastic materials, rotate
the action mode changing knob to the   symbol. Use a

twist drill bit or wood drill bit.

►

Fig.4:

1.

 Action mode changing knob

Hammering only

For chipping, scaling or demolition operations, rotate
the action mode changing knob to the    symbol. Use a

bull point, cold chisel, scaling chisel, etc.

►

Fig.5:

1.

 Action mode changing knob

Torque limiter

NOTICE:

As soon as the torque limiter actuates,

switch off the tool immediately.

 This will help pre-

vent premature wear of the tool.

NOTICE:

Drill bits such as hole saw, which tend

to pinch or catch easily in the hole, are not appro-

priate for this tool.

 This is because they will cause

the torque limiter to actuate too frequently.

The torque limiter will actuate when a certain torque

level is reached. The motor will disengage from the

output shaft. When this happens, the drill bit will stop

turning.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and unplugged before carrying out

any work on the tool.

Side grip (auxiliary handle)

CAUTION:

Always use the side grip to ensure

safe operation.

CAUTION:

After installing or adjusting the

side grip, make sure that the side grip is firmly

secured.

Install the side grip so that the protrusions on the grip fit

in between the grooves on the tool barrel. Then tighten

the thumb screw clockwise to fix the grip at the desired

position.

The side grip can be swung 360° so as to be secured at

any position.

►

Fig.6:

1.

 Side grip

2.

 Thumb screw

3.

 Tighten

4.

 Loosen

Grease

Coat the shank end of the drill bit/chisel beforehand with

a small amount of grease (about 0.5 - 1 g).

This chuck lubrication assures smooth action and lon-

ger service life.

Installing or removing drill bit/chisel

Clean the shank end of the drill bit/chisel and apply

grease before installing the drill bit/chisel.

►

Fig.7:

1.

 Shank end of the drill bit/chisel

2.

 Grease

Insert the drill bit/chisel into the tool. Turn the drill bit/

chisel and push it in until it engages.

After installing the drill bit/chisel, always make sure that

the drill bit/chisel is securely held in place by trying to

pull it out.

►

Fig.8:

1.

 Drill bit/chisel

To remove the drill bit/chisel, pull the chuck cover down

all the way and pull the drill bit/chisel out.

►

Fig.9:

1.

 Drill bit/chisel

2.

 Chuck cover

Chisel angle (when chipping,

scaling or demolishing)

The chisel can be secured at the desired angle. To

change the chisel angle, rotate the action mode chang-

ing knob to the O symbol. Turn the chisel to the desired

angle.

►

Fig.10:

1.

 Action mode changing knob

Rotate the action mode changing knob to the   sym-

bol. Then make sure that the chisel is securely held in

place by turning it slightly.

Depth gauge

The depth gauge is convenient for drilling holes of

uniform depth. Loosen the thumb screw and adjust

the depth gauge to the desired depth. After adjusting,

tighten the thumb screw firmly.

►

Fig.11:

1.

 Thumb screw

2.

 Depth gauge

NOTE:

 The depth gauge cannot be used at the posi-

tion where the depth gauge touches against the gear

housing/motor housing.
