19 ENGLISH

NOTICE:

Clean the dust and dirt on the tool

before installing the wireless unit.

 Dust or dirt

may cause malfunction if it comes into the slot of the

wireless unit.

NOTICE:

To prevent the malfunction caused by

static, touch a static discharging material, such

as a metal part of the tool, before picking up the

wireless unit.

NOTICE:

When installing the wireless unit,

always be sure that the wireless unit is inserted

in the correct direction and the lid is completely

closed.

1.

  Open the lid on the tool as shown in the figure.

►

Fig.41:

1.

 Lid

2.

Insert the wireless unit to the slot and then close

the lid.

When inserting the wireless unit, align the projections

with the recessed portions on the slot.

►

Fig.42:

1.

 Wireless unit

2.

 Projection

3.

 Lid

4.

 Recessed portion

When removing the wireless unit, open the lid slowly.

The hooks on the back of the lid will lift the wireless unit

as you pull up the lid.

►

Fig.43:

1.

 Wireless unit

2.

 Hook

3.

 Lid

After removing the wireless unit, keep it in the supplied

case or a static-free container.

NOTICE:

Always use the hooks on the back of

the lid when removing the wireless unit.

 If the

hooks do not catch the wireless unit, close the lid

completely and open it slowly again.

Tool registration for the vacuum

cleaner

NOTE:

 A Makita vacuum cleaner supporting the

wireless activation function is required for the tool

registration.

NOTE:

 Finish installing the wireless unit to the tool

before starting the tool registration.

NOTE:

 During the tool registration, do not pull the

switch trigger or turn on the power switch on the

vacuum cleaner.

NOTE:

 Refer to the instruction manual of the vacuum

cleaner, too.

If you wish to activate the vacuum cleaner along with

the switch operation of the tool, finish the tool registra

-

tion beforehand.

1.

Install the batteries to the vacuum cleaner and the

tool.

2.

Set the stand-by switch on the vacuum cleaner to

"AUTO".

►

Fig.44:

1.

 Stand-by switch

3.

Press the wireless activation button on the vac-

uum cleaner for 3 seconds until the wireless activation

lamp blinks in green. And then press the wireless acti-

vation button on the tool in the same way.

►

Fig.45:

1.

 Wireless activation button

2.

 Wireless

activation lamp

If the vacuum cleaner and the tool are linked success-

fully, the wireless activation lamps will light up in green

for 2 seconds and start blinking in blue.

NOTE:

 The wireless activation lamps finish blinking

in green after 20 seconds elapsed. Press the wireless

activation button on the tool while the wireless acti-

vation lamp on the cleaner is blinking. If the wireless

activation lamp does not blink in green, push the wire-

less activation button briefly and hold it down again.

NOTE:

 When performing two or more tool registra-

tions for one vacuum cleaner, finish the tool registra

-

tion one by one.

Starting the wireless activation

function

NOTE:

 Finish the tool registration for the vacuum

cleaner prior to the wireless activation.

NOTE:

 Refer to the instruction manual of the vacuum

cleaner, too.

After registering a tool to the vacuum cleaner, the

vacuum cleaner will automatically runs along with the

switch operation of the tool.

1.

Install the wireless unit to the tool.

2.

Connect the hose of the vacuum cleaner with the

tool.

►

Fig.46

3.

Set the stand-by switch on the vacuum cleaner to

"AUTO".

►

Fig.47:

1.

 Stand-by switch

4.

Push the wireless activation button on the tool

briefly. The wireless activation lamp will blink in blue.

►

Fig.48:

1.

 Wireless activation button

2.

 Wireless

activation lamp

5.

Pull the switch trigger of the tool. Check if the

vacuum cleaner runs while the switch trigger is being

pulled.
To stop the wireless activation of the vacuum cleaner,

push the wireless activation button on the tool.

NOTE:

 The wireless activation lamp on the tool will

stop blinking in blue when there is no operation for

2 hours. In this case, set the stand-by switch on the

vacuum cleaner to "AUTO" and push the wireless

activation button on the tool again.

NOTE:

 The vacuum cleaner starts/stops with a delay.

There is a time lag when the vacuum cleaner detects

a switch operation of the tool.

NOTE:

 The transmission distance of the wireless unit

may vary depending on the location and surrounding

circumstances.

NOTE:

 When two or more tools are registered to one

vacuum cleaner, the vacuum cleaner may start run-

ning even if you don't pull the switch trigger because

an other user is using the wireless activation function.
