18 ENGLISH

Set the action mode changing knob to the

 symbol.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.
Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the drill bit partially from the hole.

By repeating this several times, the hole will be cleaned

out and normal drilling may be resumed.

NOTE:

 Eccentricity in the drill bit rotation may occur

while operating the tool with no load. The tool auto-

matically centers itself during operation. This does not

affect the drilling precision.

Chipping/Scaling/Demolition

Set the action mode changing knob to the  symbol.

Hold the tool firmly with both hands. Turn the tool on

and apply slight pressure on the tool so that the tool will

not bounce around, uncontrolled.

Pressing very hard on the tool will not increase the efficiency.

►

Fig.34

Drilling in wood or metal

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

NOTICE:

Never use “rotation with hammering”

when the drill chuck is installed on the tool.

 The

drill chuck may be damaged.

Also, the drill chuck will come off when reversing the tool.

NOTICE:

Pressing excessively on the tool will

not speed up the drilling.

 In fact, this excessive

pressure will only serve to damage the tip of your drill

bit, decrease the tool performance and shorten the

service life of the tool.

Set the action mode changing knob to the   symbol.

Attach the chuck adapter to a keyless drill chuck to

which 1/2"-20 size screw can be installed, and then

install them to the tool. When installing it, refer to the

section “Installing or removing drill bit”.

►

Fig.35:

1.

 Drill chuck assembly

2.

 Chuck adapter

Diamond core drilling

NOTICE:

If performing diamond core drilling

operations using “rotation with hammering”

action, the diamond core bit may be damaged.

When performing diamond core drilling opera-

tions, always set the action mode changing knob to

the   position to use "rotation only" action.

Beating dust on the filter

Optional accessory

CAUTION:

Do not turn the dial on the dust case

while the dust case is removed from the dust collec

-

tion system.

 Doing so may cause dust inhalation.

CAUTION:

Always switch off the tool when

turning the dial on the dust case.

 Turning the dial

while the tool is running may result in the loss of

control of the tool.

By beating the dust on the filter inside the dust case,

you can keep the vacuum efficiency and also reduce

the number of times to dispose of the dust.

Turn the dial on the dust case three times after col-

lecting every 50,000 mm

3

 of dust or when you feel the

vacuum performance declined.

NOTE:

 50,000 mm

3

 of dust equivalents to drilling 10

holes of ø10 mm and 65 mm depth (14 holes of ø3/8″

and 2″ depth).

►

Fig.36:

1.

 Dust case

2.

 Dial

Disposing of dust

Optional accessory

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

CAUTION:

Be sure to wear dust mask when

disposing of dust.

CAUTION:

Empty the dust case regularly

before the dust case becomes full.

 Failure to do so

may decrease the dust collection performance and

cause dust inhalation.

CAUTION:

The performance of dust collection

decreases if the filter in the dust case become

clogged. Replace the filter with new one after

approximately 200 times of dust fulfillment as a

guide.

 Failure to do so may cause dust inhalation.

1.

  Remove the dust case while pressing down the

lever of the dust case.

►

Fig.37:

1.

 Lever

2.

  Open the cover of the dust case.

►

Fig.38:

1.

 Cover

3.

  Dispose of the dust, and then clean the filter.

►

Fig.39

NOTICE:

When cleaning the filter, tap the case

of the filter gently by hand to remove dust. Do not

tap the filter directly; touch the filter with brush

or similar; or blow compressed air on the filter.

Doing so may damage the filter.

Blow-out bulb

Optional accessory

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

►

Fig.40
