16 ENGLISH

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Side grip (auxiliary handle)

CAUTION:

Always use the side grip to ensure

safe operation.

CAUTION:

After installing or adjusting the

side grip, make sure that the side grip is firmly

secured.

Install the side grip so that the grooves on the grip fit in

the protrusions on the tool barrel. Turn the grip clock-

wise to secure it. The grip can be fixed at desired angle.

►

Fig.11:

1.

 Side grip

Grease

Coat the shank end of the drill bit beforehand with a

small amount of grease (about 0.5 - 1 g).

This chuck lubrication assures smooth action and lon-

ger service life.

Installing or removing drill bit

Clean the shank end of the drill bit and apply grease

before installing the drill bit.

►

Fig.12:

1.

 Shank end

2.

 Grease

Insert the drill bit into the tool. Turn the drill bit and push

it in until it engages.

After installing the drill bit, always make sure that the

drill bit is securely held in place by trying to pull it out.

►

Fig.13:

1.

 Drill bit

To remove the drill bit, pull the chuck cover down all the

way and pull the drill bit out.

►

Fig.14:

1.

 Drill bit

2.

 Chuck cover

Chisel angle (when chipping,

scaling or demolishing)

The chisel can be secured at the desired angle. To change

the chisel angle, rotate the action mode changing knob to

the O symbol. Turn the chisel to the desired angle.

►

Fig.15:

1.

 Action mode changing knob

Rotate the action mode changing knob to the   sym-

bol. Then make sure that the chisel is securely held in

place by turning it slightly.

Depth gauge

The depth gauge is convenient for drilling holes of uniform

depth. Loosen the side grip and insert the depth gauge

into the hole on the side grip. Adjust the depth gauge to

the desired depth and tighten the side grip firmly.

►

Fig.16:

1.

 Hole

2.

 Depth gauge

NOTE:

 Make sure that the depth gauge does not

touch the main body of the tool when attaching it.

Installing or removing dust

collection system

Optional accessory

To remove the dust collection system, pull the tool while pressing

the lock-off button. To install it, insert the tool into the dust collec

-

tion system all the way until it locks in place with a little click.

►

Fig.17:

1.

 Lock-off button

Dust cup

Optional accessory

Use the dust cup to prevent dust from falling over the tool and

on yourself when performing overhead drilling operations.

Attach the dust cup to the bit as shown in the figure. The size

of bits which the dust cup can be attached to is as follows.

Model

Bit diameter

Dust cup 5

6 mm - 14.5 mm

Dust cup 9

12 mm - 16 mm

►

Fig.18:

1.

 Dust cup

Dust cup set

Optional accessory

Installing the dust cup set

NOTICE:

If you purchase the dust cup set as

optional accessory, the standard side grip cannot

be used with the dust cup set being installed on

the tool.

 When the dust cup set is installed on the

tool, remove the grip from the standard side grip, and

then attach it to the optional grip base set.

►

Fig.19:

1.

 Bolt

2.

 Grip

3.

 Optional grip base set

NOTICE:

Do not use the dust cup set when drill

-

ing in metal or similar.

 It may damage the dust cup

set due to the heat produced by small metal dust or

similar. Do not install or remove the dust cup set with

the drill bit installed in the tool. It may damage the

dust cup set and cause dust leak.

Before installing the dust cup set, remove the bit from

the tool if installed.

1.

  Install the spacer so that the grooves on the spacer

fit in the protrusions on the tool barrel while widening it. Be

careful for the spring not to come off from the slit of spacer.

►

Fig.20:

1.

 Spacer

2.

 Spring

►

Fig.21

2.

  Install the side grip (optional grip base set and

the grip removed from standard side grip) so that the

groove on the grip fit in the protrusion on the spacer.

Turn the grip clockwise to secure it.

►

Fig.22:

1.

 Side grip

3.

  Install the dust cup set so that the claws of the

dust cup fit in in the slits on the spacer.

►

Fig.23:

1.

 Dust cup

2.

 Claws

NOTE:

 If you connect a vacuum cleaner to the dust

cup set, remove the dust cap before connecting it.

►

Fig.24:

1.

 Dust cap
