Technical Data

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:
Sound pressure level 91 dB(A); sound power level
102 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!
GBH 3-28 DRE:

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Hammer drilling into concrete: a

h

= 14.5 m/s

2

, K = 1.6 m/s

2

,

Chiselling: a

h

= 10 m/s

2

, K = 1.5 m/s

2

,

Drilling in metal: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

,

Screwdriving without impact: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

GBH 3-28 DFR:

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Hammer drilling into concrete: a

h

= 13 m/s

2

, K = 2 m/s

2

,

Chiselling: a

h

= 9.5 m/s

2

, K = 1.5 m/s

2

,

Drilling in metal: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

,

Screwdriving without impact: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

GBH 3-28 DRE/GBH 3-28 DFR:

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main
applications of the tool. However if the tool is used for differ-
ent applications, with different accessories or insertion
tools or is poorly maintained, the vibration emission may dif-

fer. This may significantly increase the exposure level over
the total working period.
An estimation of the level of exposure to vibration should al-
so take into account the times when the tool is switched off
or when it is running but not actually doing the job. This may
significantly reduce the exposure level over the total work-
ing period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and
the accessories, keep the hands warm, organisation of work
patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 07.10.2013

Rotary Hammer

GBH 3-28 DRE

GBH 3-28 DFR

Article number

3 611 B3A 0..

3 611 B4A 0..

Speed control





Stop rotation





Right/left rotation





Quick change chuck

–



Rated power input

W

800

800

Impact rate

min

-1

0 – 4 000

0 – 4 000

Impact energy per stroke according to EPTA-Procedure 05/2009

J

3.1

3.1

Speed

min

-1

0 – 900

0 – 900

Tool holder

SDS-plus

SDS-plus

Spindle collar diameter

mm

50

50

Permissible drilling diameter, max.:
(also see page 16)
– Concrete*
– Brickwork (with core bit)
– Steel
– Wood

mm
mm
mm
mm

28
82
13
30

28
82
13
30

Weight according to EPTA-Procedure 01/2003

kg

3.5

3.6

Protection class

/

II

/

II

*not suitable with core bit

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
