PFE/PFD

9

GB

The thermostat

The thermostat range is 5-35

o

C. Normal working area

is marked (15-25

o

C). The setting on the thermostat is

calibrated for a normal room and some experimen-

tation may be required to ind the ideal setting. A

desired temperature of 20

o

C should be found within

the marked area. See page 2.

Master/slave function

When installing several radiators, it is possible to use

one radiator as master and the others as slaves. The

radiators are then controlled by the irst radiator’s

thermostat and this gives a more even heat contribu-

tion. A maximum of 10 slaves can be connected to

one master radiator.

On radiators of model PFE (230V~) the mains

cable must be exchanged for a special 4-core cable,

202111. The 230V~ elements have a cable with three

conductors. For the master/slave function, four con-

ductors are needed. The fourth conductor is used for

the signal input to/from the thermostats.

When connecting slaves the elements may get

power from several directions. All circuits must be

broken before connection terminals are made acces-

sible.

The master/slave function must be installed by a

competent electrician. See wiring diagram page 3.

Night temperature setback

Night temperature setback, i.e the possibility to lower

the temperature at night, can be connected on both

PFE and PFD. This means that the set temperature is

lowered 4°C. Night time reduction must be installed

by a competent electrician. On radiators of model

PFE (230V~) the mains cable must be exchanged for

a special 4-core cable, 202111

. The 230V~ elements have a cable with three con-

ductors. For night temperature setback, four conduc-

tors are needed. The fourth conductor is used for the

signal input to/from the thermostats.

The cable marked NS is connected through the

time switch to the neutral conductor, see also wiring

diagrams at page 3.

To change or remove the front panel

The front panel can easily be relacquered or the ap-

pearance changed by applying a plastic ilm.

Disconnect the power before removing the front

panel, thereafter the two screws under the radiator are

loosened and the front panel is pulled downwards.

This must be done by a competent electrician.

Overheat protection

All electrical radiators are equipped with overheat

protection. The overheat protection is reset by turning

off the switch for 5 to 10 minutes. To allow the heater

to cool before resetting the power, remove any ob-

struction causing the unit to overheat. NB. Persistent

tripping of the overheat protection should be referred

to a service engineer.

Approvals

•   Models up to 800 W have a low surface tempera

ture, 60

o

C maximum, and are suitable for use in

areas where lower surface temperatures are desired.

•   Protection class: IP23.

•   PFE is approved for mounting with plug or

  permanent installation 230V~.

•   PFD is approved for permanent installation

  400V2~.

Safety

•   The radiator must not be positioned immediately

below a permanent socket.

•   Permanent installation must only be carried out by

a competent electrician.

•   Do not cover - this can result in a risk of ire!

•  The radiator must not be mounted outdoors.

•  The radiator should be positioned out of reach of

  people in showers and bathtubs.

•  Radiators for portable use must not be used close

  to pools, bathtubs or showers.

•  The radiator should be installed to ensure that

operation and maintenance can be carried out safely.

•  Before service and maintenance is started, the

  power must be disconnected and the fan wheel

  must have stopped.

Maintenance, service and reparation

The radiator should be cleaned when necessary,

recommended at least twice a year to prevent damage

on the bearings (differs depending on the indoor

environment). If the air low is obstructed it may

also lead to the overheat protection triggering off and

that the thermostat may be given wrong temperature

input. Lower the radiator forward. Vacuum the inlet

grilles on the back and underside. High pressure clea-

ning must not be used to clean the radiator. Cleaning

must be made carefully and only in exeptional cases

must the radiator be opened. The radiator must only

be opened by a competent electrician. The bearings

are maintenance free and should only be changed

when necessary. Make sure no discordant sounds are

heard from the fan. Make sure that the fan wheel is

not blocked. If the fan doesn’t start after operation

and/or reset of the overheat protection, contact the

supplier. A damaged mains cable must only be chan-

ged by a competent electrician.
